Ordering numbers, 380 - 415 V

AHF 005 and AHF 010, 380V - 415V, 50Hz
I Typical Motor
AHF,N
Used [kW]
10 A 4, 5.5
19 A 7.5
26 A 11
35 A 15, 18.5
43 A 22
72 A 30, 37
101 A 45. 55
144 A 75
180 A 90
217 A 110
289 A 132, 160
324 A
Higher ratings can be achieved by paralleling the filter units
360 A 200
434 A 250
578 A 315
613 A 355
* Please note that the matching of the typical Danfoss frequency converter and filter is pre-calculated based
on 400V and assuming typical motor load (4 or 2 pole motor). VLT 5000 series is based on a max. 160 %
torque application, while VLT 6000 and 8000 series are based on a max. 110% torque application.
The pre-calculated filter current may be different than the input current ratings of VLT 5000, VLT 6000
and VLT 8000 series as stated in the respective operating instructions, as these numbers are based on
different operating conditions.
4
Danfoss ordering number
AHF 005 AHF 010
175G6600 175G6622
175G6601 175G6623
175G6602 175G6624
175G6603 175G6625
175G6604 175G6626
175G6605 175G6627
175G6606 175G6628
175G6607 175G6629
175G6608 175G6630
175G6609 175G6631
175G6610 175G6632
175G6611 175G6633
Two 180 A units
Two 217 A units
Two 289 A units
289 A and 324 A units
AHF 005/010
Typical Danfoss frequency converter series
VLT 5000 VLT 6000 HVAC
5006, 5008 6006, 6008
5011 6011, 6016
5016 6022
5022, 5027 6027
5032 6032
5042, 5072 6042, 6052
5062, 5072 6062, 6072
5102 6102
5125 6122
5150 6150
5200, 5250 6175, 6225
5300
5350
5450
5500
