38 en | Operation
8.3

Call Station operation

The following figure lists all items of the Call Station. This section only describes the operation
of the Call Station. For information on connecting and configuring the Call Station, refer to:
–
–
–
The PLN‑6CS Call Station is used for making announcements to selected zones of the
All‑in‑One system.
2
3
5
Figure 8.6: PLN‑6CS Call Station functions
Number Item
1 Goose neck condenser
microphone
2 Zone buttons / Zone LEDs
(1-6)
2014.09 | V1.2 |
Call Station connections, page 18
Call Station hardware configuration, page 24
Call Station software configuration, page 25
1 7
4
Description
A high quality unidirectional microphone.
– To select a zone, press a zone button and the corresponding zone
LED will go on.
– To deselect a zone, press the zone button again and the zone LED
will go out.
Installation and Operating Manual
6
Plena All-in-One System
8
11 9
12
Bosch Security Systems B.V.
10
