- Page 1 CHECK •LINE ® BY ELECTROMATIC Analog Durometer Model AD-100 Operating Instructions...
-
Page 2: Table Of Contents
Table of Contents 1.0 Introduction ................1.1 Unpacking 1.2 Complete Kit 2.0 Testing Procedure ................3.0 Memory Pointer ................4.0 Specifications ................4.1 Conforms to International Standards ..........4.2 Dimensional Drawings 5.0 Calibration & Repair ................6.0 Warranty ................– 1 –... -
Page 3: Introduction
Introduction The new Check-Line AD-100 analog durometer is the ideal choice for a wide range of Shore hardness measuring applications. The AD-100 displays hardness readings on an easy-to-read analog scale calibrated in 0 to 100 Shore units. Seven scales are available: A, B, C, D, DO, O, OO. -
Page 4: Testing Procedure
Testing Procedure 1. Place the instrument on the material to be tested. The durometer must be level and perpendicular to the specimen. Any angle other than perpendicular (90°) may cause errors. NOTE: If the gauge is equipped with the Memory Pointer option make sure the pointer is returned to zero before starting. -
Page 5: Memory Pointer
memory Pointer (optional) The Memory Pointer moves mEmOry POINT- with the measurement pointer when a measurement is taken. However, when pressure on the KNurlEd KNOb specimen is released, and the measurement pointer returns to zero, the Memory Pointer remains in position, marking the last measurement. -
Page 6: Specifications
* NOTE: per ASTM D 2240-05, Sect 9.3: It is accepted that durometer readings be- low 20 or above 90 are not considered reliable. It is suggested that readings in these ranges be omitted. Conformance to International Standards Model ASTM D2240 DIN 53505 ISO 868 ISO 7619 AD-100-A ● ● ● ● AD-100-B ●... -
Page 7: 4.1 Dimensional Drawings
4.1 Dimensional Drawings 1.00 in (25.4mm) 2.24 in (57mm) 5.04 in (128mm) 0.79 in (20mm) 0.98 in (25mm) 0.71 in (18mm) – 6 –... -
Page 8: Calibration & Repair
Calibration and repair All Check Line durometers requiring calibration and/or certification should be sent directly to ELECTROMATIC Equipment Co., Inc. – 7 –... -
Page 9: Warranty
Warranty ELECTROMATIC Equipment Co., Inc. (ELECTROMATIC) warrants to the original purchaser that this product is of merchantable quality and confirms in kind and quality with the descriptions and specifications thereof. Product failure or malfunction arising out of any defect in workmanship or material in the product existing at the time of delivery thereof which manifests itself within one year from the sale of such product, shall be remedied by repair or replacement of such product, at ELECTROMATIC’s option, except where unauthorized repair, disassembly, tampering, abuse or... - Page 10 Distributed by: ABQ Industrial LP USA Tel: +1 (281) 516-9292 / (888) 275-5772 eFax: +1 (866) 234-0451 Web: https://www.abqindustrial.net E-mail: info@abqindustrial.net...
