• Technical data •
A
Technical data:
• Power supply: 400V/50Hz/3~, 220V/60Hz/3~
• Cutting length: 720 mm
• Cutting height: 80 mm
• Table depth: 720 mm
• Sound level EN 13023: 72 dB (A)
• Minimum space requirement
(width x depth x height)
1
1305/2100 mm x 1500/1600
• Leakage current < 3,5mA
• Power cord gauge min. 1,5mm
• Power cord gauge AWG 14 (20A) (220V)
• Clamping pressure: min. 250 daN,
max 2000 daN
• Weight: 613 kg, 620 kg
• Capacity of hydraulic oil: 1,5 l
HLPD, viscosity 46 mm
Used oil must be disposed of at the
authorised place.
1
with side tables
The exact technical specifications can be
found on the technical specifications sticker (A)
on the machine. A wiring diagram is found in
the electrical switch box.
To claim under guarantee, the machine must
still carry its original identification label.
Safety light beam
• Total reaction time:101 ms
• Resolution 14 mm/minimum distance:370 mm
• Resolution 30 mm/minimum distance:480 mm
• Resolution 40 mm/minimum distance:468 mm
Ambient operating temperature 10 °C - 60 °C
Air humidity (not condensating) 15 % - 95 %
Krug + Priester has a certified quality
management system according to DIN EN
ISO 9001:2008 and a certified environmental
management system according to DIN ISO
14001:2009.
- 45 -
1
mm x 1355 mm
2
(400V)
1
2
/ sec. to DIN 51562.
