KIT INSTRUCTIONS which came with the kit. It contains replacement parts numbers needed for ordering future parts. NOTE: The manual part number is located on the lower right corner of the front cover. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
When ordering parts, please specify model and serial number. Use only identical replacement parts. This machine is to be used only by trained operators. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
EYE WEAR, GLOVES AND FOOTWEAR be cleaned. WHEN OPERATING. 4. Never make adjustments on machine while it is in operation except those prescribed in this manual. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 7
16. Do not operate the machine with the lid or door open and do not override the safety switch. 17. After the machine stops, wait 10 seconds before opening the lid or door. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
, ad d the er’ • g the : Dis e ad Sump Cover Fresh Water In Low Water Shut-Off Assy. Pump Heating Element & Thermostat Enclosure CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Spray Sink Tr ay Manifold Latch ts Tree (Optional) Door Latch Power Turntable Brush (Optional) Detail Brush (Optional) Turntable Chain Small Pa Basket Oil Drain Container Containment Ring Side Sink/Pump (Optional) Sump Cover CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
In addition, the optional 24- hour, 7-day heater and oil skimmer timer allows you to schedule the oil skimmer to operate while the machine sits idle. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Operations Main Operating Components Models 2840, 2840, and 2848 machines are available with a 24-hour, 7-day heater timer or a 24-hour, 7-day Familiarize yourself with the main operating compo- heater and oil skimmer timer. The heater timer controls nents before operating the machine.
Position 2: Detail Brush free spray nozzle operation, and also provides a safeguard against small parts that might accidentally be To Air washed through from the cleaning chamber. Outlet Supply To Detail Brush CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Operations Detail Tray and Sump Assembly (Optional) NOTE: The power brush is a standard component on the Deluxe Kit version of the models 2840 and 2848. Detail Tray It is available as an option on the base models. To order a Deluxe Kit option package, contact your The detail tray is located on the right side of the distributor or call customer service.
Both Switches OPEN, Automatic OPEN, Automatic Water Fill Valve (if CLOSED, Automatic Water Fill Valve (if Water Fill Valve (if installed) installed) OPEN, Heating Element Off. installed) OPEN, Heating Element OFF. CLOSED, Heating Element ON. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Follow recommended detergent quanti- ties. Use a pH kit to determine the proper amount of detergent to use. If you need help interpreting test results, contact customer service. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Hold for a continuous wash. 4. When the machine automatically stops (or after you manually stop the wash cycle), open the door and wait a few moments to allow the parts to cool CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Lubricate the door spindle using high-quality automotive grease. Add grease until it begins to Grease Fitting flow out of the joint beneath the grease fitting, then wipe excess grease from the fitting and the joint. Grease Fitting CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Under normal skimming conditions (when the wash solution is cool) the thermal overload should not trip. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
1. If your machine is equipped with a detail sump, dump the contents of the detail sump into the main sump chamber. 2. Remove oil and grease from the cleaning solution using the oil skimmer system (See Using the Oil Skimmer System). CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Nylon bags are reusable; polyester felt bags are designed for a single use. To clean or 9. Tighten the pressure-release plug. replace the filters, perform the following procedure: 10. Turn on machine and continue washing. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
The element may be difficult to remove. When you install a new heating element, use sealing tape or compound on the threads to deter corrosion. 6. Install the new heating element(s). Installation is the reverse of removal. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
1. Disconnect power to the machine. machine, then reach into the drive pulley access hole with your fingers to free the chain from the drive pulley. Take care not to let the chain slip into CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Oil Skimmer Motor Required Tools and Equipment • •5/16” wrench or socket • • 1/2” wrench or socket Wire Nuts • • small phillips-head screwdriver Replacement Procedure 1. Disconnect power to the machine. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Electrical troubleshooting should be performed by qualified personnel only. • Avoid contact with power leads, terminals and fuses when power is connected. • Disconnect power to machine before removing fuses or other electrical components. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 27
One of the Pump Fuses Power is Blown; Replace the Fuses; Measure the Blown Fuse Resistance of Each approximately 0 Ohms Pump Electrical Panel is OK, Refer to Testing Overload Individual Components Relay CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 28
(four screws; use a 5/16” mostat out of the mounting bracket, then remove it wrench or socket). from the machine. 5. Set the thermostat to 120°F, warm it to just above 120°F, then test for continuity. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 29
If the ohm meter reads approximately 1 Ohm, the start capacitor is no longer functional; replace the start capacitor. CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 30
Check the thermostat to ensure that it Thermostat is incorrectly installed is correctly installed into the mounting WASH bracket. (See Thermostat Section). SOLUTION IS TOO HOT Replace the thermostat Failed thermostat (See Thermostat Section). CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Pump is failed licensed electrician or a customer service representative to test the pump motor. OIL SKIMMER DOES NOT Check electrical panel for a blown fuse; replace if Blown fuse OPERATE necessary. PROPERLY CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 32
OF MACHINE correct amount to add. Verify that you are using our IS RUSTING detergents at the correct concentration. Condensation on door and cabinet causing rust during idle Leave door open. periods CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Cuda 2848 Front For Detail See Latch Assy Field Installed CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 35
8.915-208.0 ASSY, CABINET 2848 8.915-447.0 ASSY, CABINET, 2848, W/12" HGT EXT 8.921-864.0 ASSY, CABINET, 2848, SS 8.921-927.0 ASSY, CABINET, 2848, W/12" HGT EXT, SS 8.915-213.0 ASSY, DOOR 2848 8.915-452.0 ASSY, DOOR, 2848, W/12" EXT 8.921-899.0 ASSY, DOOR 2848, SS 8.921-932.0 ASSY, DOOR 2848, W/12"...
Page 36
W/12" HGT EXT 8.713-038.0 WHEEL, TRACK 8.753-682.0 WHEEL, TRACK, SS 8.713-266.0 E-CLIP, 1/4" MILD STEEL 8.753-763.0 E-CLIP, 1/4" STAINLESS STEEL 8.718-603.0 BOLT, 1/4" X 3/4", NC HH SS 8.718-965.0 WASHER, 1/4", FLAT, SAE, SS CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 37
CAP, VINYL BLACK, 1/4" X 3/4" LG 8.731-254.0 PARTS BASKET -SMALL 8 X 8 X 4 NOT SHOWN 8.705-957.0 CONTAINMENT RING-28 INCH, MARKED RED NOT SHOWN 8.915-124.0 PARTS TREE, 4 HOOK, 27" X 24" NOT SHOWN CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
: Dis form d and y of • d qua ntit from n cle • grit p has into r ma r’s ter, • t for : Dis t to CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 39
PIPE, BARBED/MALE NPT 1-1/2" STAINLESS 8.706-195.0 ELBOW, 90° 1-1/2" FEMALE, BLACK 8.706-192.0 ELBOW, 90° 1-1/2" FEMALE, SS 8.735-005.0 NIPPLE, 1-1/2" X 2.5" LG SCH 40 8.753-616.0 NIPPLE, 1-1/2" X 2.5" LG SCH 40 SS CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 40
SCREW, 4-40 X 1/2" SLOTTED P/H M/S ZINC 8.922-402.0 LABEL, WARNING, INSTRUCTIONS CUDA APW 9.807-513.0 LABEL, CUDA APPROVED DETERGENTS 9.800-034.0 LABEL, CLEAR LEXAN 9.800-016.0 LABEL, DISCO POWER SUPPLY 9.803-831.0 CONNECTOR, 3/4" L/T, 90° BLACK CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
Page 41
SCREW 3/8" X 1-1/4" HH, CS, SS 9.800-013.0 LABEL, ASSEMBLED USA 9.800-040.0 LABEL, GROUND SYMBOL 8.718-810.0 SCREW 10/32" X 1/2" WHIZ LOC 9.803-249.0 SCREW M 4 X 10 (3 PH ONLY) 8.718-978.0 WASHER, 1/4", SPLIT-RING LOCK, SS CUDA 2848 Operator’s Manual 8.930-369.0 - AG...
