  • Page 1 Rev 1.1 Network Camera (“M” Series) User Manual...
  • Page 2 Network Camera_ User manual Revision History: Date Rev No Description Dec. 1th, 2013 Creation of the Document Feb. 20th, 2014 Modified “2.7. Video Setup - ISP Module Adjust” Indications: Warning : Death or Serious Injury will occur without following Warning. Caution : Operational Problem(Faulty &...

  • Page 3: Table Of Contents

    Network Camera_ User manual Contents PREPARATION FOR THE CONNECTION ................... 4 1.1. Product Installation ......................4 1.2. PC Requirements ........................6 CONFIGURATION IN ADMIN MODE ..................7 2.1. Access ..........................7 2.2. Layout of the admin mode ....................9 2.3. Basic Setup ........................

  • Page 4: Preparation For The Connection

    Network Camera_ User manual 1. Preparation for the connection 1.1. Product Installation Brief information for rapid installation is provided in this section. For more detailed information you are recommended to refer to pertinent documentations provided with the product. Apply Power to the product and connect the product with network cable. Applying improper power to device can cause damage to the device.
  • Page 5 Network Camera_ User manual < Quick Installation Guide of IP-Installer > Install the IP Installer on the PC or Laptop. The WinPCap installed together is required software for the operation of IP-Installer. Please install the WinPCap essentially as when it is not installed, IP Installer won’t operate.

  • Page 6: Pc Requirements

    Network Camera_ User manual Fig. 1-2. IP-Installer Parameter Setting Up 1.2. PC Requirements AV streaming data received from IP camera or video server can be decoded or stored in a PC running NVR-PRO program or other CMS program. Minimum requirement of the PC is recommended as in the following table.

  • Page 7: Configuration In Admin Mode

    Network Camera_ User manual 2. Configuration in Admin Mode The detailed operational parameters of the product can be configured through Admin Mode via network. 2.1. Access The access to Admin Mode can be done using 2 ways; through Internet Explorer and the “NVR-Pro” program.
  • Page 8 Network Camera_ User manual Input User Name and Password in the display screen shown below. Factory default “User Name” and “Password” are set as “root” and “admin”, respectively. Click on “OK” button to enter into the Basic Setup page of Admin mode. If you have changed the username and password of the Administrator, you must log on with the changed username and password.

  • Page 9: Layout Of The Admin Mode

    Network Camera_ User manual 2.2. Layout of the admin mode Upon initiation of the admin mode, the screen similar to the following picture will be shown. The left side of the admin page shows various admin Mode menus, while the right side shows the settings of selected admin menu.

  • Page 10: Basic Setup

    Network Camera_ User manual 2.3. Basic Setup Setup the basic parameters for the operation of the product. Fig. 2-3. Basic Setup Item Description Logical name of the product. It is same as the one set-up by IP-installer. System Name You can reassign the logical name. The system name will be shown in the connection through NVR-Pro.
  • Page 11 Network Camera_ User manual Baseline : Primarily for low-cost applications like as videoconferencing and mobile applications. Main : Used for standard-definition digital TV broadcasts. High : primary profile for broadcast and disc storage applications, particularly for high-definition television applications (for example, Blu-ray and the DVB HDTV) Select profile for your circumstance.

  • Page 12: Network Setup

    Network Camera_ User manual 2.4. Network Setup Setup the network parameters appropriately in accordance with your network environment. Many of the parameters in this mode are same as those set up by “IP-Installer”. Fig. 2-4. Network Setup Item Description The network types supported by the products are LAN(fixed IP), PPPoE, and DHCP(automatic IP allocation).
  • Page 13 Network Camera_ User manual When the DHCP server assigns IP address automatically, select ‘DHCP’ in the network type. Select this mode in case of Cable Modem. DHCP Setup Refer to [IP-installer user’s guide] for “Host name and domain for Cable Modem. Clone MAC Refer to [IP-installer user’s guide]...

  • Page 14: 802.1X Setup

    Network Camera_ User manual If you want to register a hostname with a specific user account at autoipset.com server, Please make an account from (http://www.autoipset.com) Save the set-up parameters when parameters settings are finished. SAVE You must click the “Save” once you finish the all settings. 2.5.

  • Page 15: Onvif Setup

    Network Camera_ User manual followings: EAP-MD5 : Username, Password EAP-TLS : CA Certificate, Client Certificate, Private Key, Username, Setup Private Key Password PEAP : CA Certificate, Username, Password EAP-TTLS : CA Certificate, Username, Password Username Account name of client. Password Password for the account Private Key Password for Private Key.

  • Page 16: Video Setup

    Network Camera_ User manual 2.7. Video Setup You can adjust the parameters of input video. Note that parameters will vary in accordance with the camera module employed. Fig. 2-6. Video Setup Item Description Contrast Adjust contrast. Default is 50. Brightness Adjust Brightness.
  • Page 17 Network Camera_ User manual Fig. 2-7. ISP Module Setup Item Description Set the WDR mode ON or OFF. Synchronize the video frequency with Power Frequency of your Anti Flicker region to remove flickering. (OFF, 60Hz, 50Hz) Enhance the Video image under the low light condition by Slow FPS controlling the shutter speed.

  • Page 18: User Admin & Time Setup

    Network Camera_ User manual 2.8. User Admin & Time Setup You can change the ID and password of users and also assign different attributes to each user. Once the required setting-up is finished, please click the “Save” to save the setting values. Fig.
  • Page 19 Network Camera_ User manual You can assign different privileges to users for the access to system resources. Add User Attributes are Audio, Bi-directional Audio and Pan/Tilt control. Attribute For example, if you want a specified user to hear the audio from the device, check Audio in the check box.

  • Page 20: Sensor & Capture Setup

    Network Camera_ User manual 2.9. Sensor & Capture Setup This is the setup mode for sensors and video capture conditions. Captured video can be sent to user by FTP or (and) E-mail, or stored on local storage. Fig. 2-9. Sensor & Capture Setup Item Description Select sensor type.
  • Page 21 Network Camera_ User manual Video Audio Enable/Disable Audio Detection event. Transmission methods applied Capture Detection for motion event is applied for transmission. Condition Select Select a way of sending captured video E-Mail Transmit to the desired E-mail address configured at Transmission [Network Configuration] Transmit to the desired FTP Server configured at...

  • Page 22: E-Mail & Ftp Setup

    Network Camera_ User manual Select Date Set time begin and end time. The time can be set in the increment of Time 30 minutes. Save the setup parameters. SAVE You must click on “SAVE” to apply the setting values. 2.10. E-Mail & FTP Setup Configure E-mail and FTP connection information.

  • Page 23: Alarm Device Setup

    Network Camera_ User manual If you are using web mail services having no SMTP server, check the radio Using Built-in button at the left of “Using Built-in SMTP Server” and enter active and SMTP Server valid e-mail address to avoid spam filtering on the receiving e-mail server. Using E-Mail External...

  • Page 24: Motion Detection Setup

    Network Camera_ User manual Duration Set the duration of Alarm annunciation. Save the setup parameters. SAVE You must click on “SAVE” to apply the setting values. 2.12. Motion Detection Setup Set the motion detection regions. Up to 3 regions can be defined. Fig.
  • Page 25 Network Camera_ User manual Setup 1, 2, or 3 Even you configure the region, motion detection will not be enabled if you don’t check the box. Legend of the color : Red, Green, 3 : Blue Set entire region of video as motion region. Selection ALL Clear Erase the configured region.

  • Page 26: Audio Detection

    Network Camera_ User manual 2.13. Audio Detection Set the audio detection level. Audio detection is treated as a motion detection in the system. Fig. 2-13. Audio Detection Setup Item Description Set the sensitivity of audio detection for each channel. Default is 50. Audio Detection The Lower the value, the higher the sensitivity.

  • Page 27: Ptz Setup

    Network Camera_ User manual 2.14. PTZ Setup PTZ Setup is available on the models having Pan/Tilt/(Zoom) functions. You can configure PTZ parameters using Web Viewer or NVR-pro, too. Fig. 2-14. PTZ Setup Item Description Select the Protocol which is used by PTZ Camera. PTZ Model Selection Delete Button...

  • Page 28: Upgrade & Reset

    You must restart the system by “System Restart” to run the system with the upgraded system software. Fig. 2-14. Upgrade & Reset Contents of the upgradable system component should be downloaded from CNB’s home page before the system upgrade is performed.
  • Page 29 Network Camera_ User manual Re-initialize the system to factory default state. By checking on a Radio button “Except Network Configuration”, you can preserve the parameters for the network in case of remote upgrade. Factory Default Setting Checking on “All”, will return all the parameters to factory default state. Once all the values are set to factory default state, the product should be set-up again using IP-Installer.
  • Page 30 Followings are the procedure to apply for the manual upgrade Save the upgrade system software to your PC. Upgrade software can be downloaded from CNB’s home page or provided in CD. Connect to the product in admin mode and select “Update & Reset” menu.

  • Page 31: Status Report

    Network Camera_ User manual 2.16. Status Report It shows you system records since the system started. Fig. 2-16. System Status Information With this System Status Information, you can check whether the system upgrade has been done correctly or not, as well as the versions and event status of the whole system and modules. Item Description Download template file...

  • Page 32: Web Viewer

    Network Camera_ User manual 3. Web Viewer 3.1. Web Viewer IP camera and video server provide video connection over the internet explorer. The web viewer might be different on different product. Video crop function is available from the web viewer. Control Keys Admin Mode Connection Video Crop Control...

  • Page 33: Buttons And Indicators Of Web Viewer

    Network Camera_ User manual 3.2. Buttons and Indicators of Web Viewer. Item Description On/Off control of bidirectional audio communication. Bidirectional audio communication is enabled when highlighted. If the microphone is not connected to PC to set up the bidirectional audio, an error message is indicated and the temporarily stopped image my occur.

  • Page 34: Crop Video Setting

    Network Camera_ User manual 3.3. Crop Video Setting The position, size and the frame rate of the crop video can be set in the web viewer. The blue area in the figure below shows the crop window from a 1920x1080 image sensor. Set the position as (250, 250) and the size as the desired.

  • Page 35: Ptz Control Menu

    Network Camera_ User manual 3.4. PTZ Control Menu You can control the PTZ of PTZ-enabled product by using PTZ menu control buttons on the Web Viewer. Item Description Camera Position Control Pan/Tilt control Zoom In Zoom Out Focus Far Focus Near Enter into OSD menu for camera setting.
  • Page 36 Network Camera_ User manual Stop any PTZ command Enable Auto PTZ Check for using auto tracking function Tracking Auto PTZ Tracking Enable Zoom Check for zoom control Setup Control If there is no motion, camera comes back preset position. If no motion Select second and preset you set.
  • Page 37 Network Camera_ User manual angle). If counterclockwise direction was set, the scanning covers the wide region, while the scanning covers narrow region if clockwise direction was selected. Note : Endless Function of OSD Menu should be Off. Select the rotational direction of camera, when Endless Rotation is On.
  • Page 38 Network Camera_ User manual DISPLAY Display region for privacy mask. Move or Adjust the position and size of privacy mask by selecting MOVE and ADJUST. ACTION To adjust the size, select ADJUST and press the Focus Far button, Adjust the size using PT Direction Key and ave by pressing the Focus Far Button.

  • Page 39: Trouble Shooting And Tips

    Network Camera_ User manual 4. Trouble Shooting and Tips 4.1. Trouble shooting after installation 4.1.1. Neither channel name nor video is shown up and eventually timeout message is sho Check the power and network connection of device. To check if the network is properly operating, open the browser and try to connect to any server. Example) http://www.google.com Or open the MS-DOS Prompt and type the following ping www.google.com...

  • Page 40: Trouble Shooting After Successful Connection To The Device

    Network Camera_ User manual 4.1.2. The name of the server is shown but no video is available (Only the Frame of Web Viewer) In this case, network connection is not a problem. Please do the followings: Check whether the video is properly applied into the product. Check whether there is firewall between the product and the client and check whether the network is NAT type.
