Summary of Contents for CNB ISS2000 Series
- Page 1 Outdoor Speed Dome Series IP-XNET Ver 1.0 INSTALLATION AND OPERATION MANUAL / ISS2000 Series (3810-0203A)
-
Page 2: Important Safety Instructions
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà This lightning flash with arrowhead symbol is intended to alert The user to the presence of un-insulated “dangerous voltage” Within the product’s enclosure that may be of sufficient magnitude To constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to The presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 3: Table Of Contents
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà ⊙ Table of Contents 1. Introduction Features Product & Accessories Parts Name & Functions 2. Installation Dip Switch Setup Installation Using the Wall Mount Installation Using the Pendant Mount Wire Connections 3. Operation Check Points before Operation Preset and Pattern Function Pre-Check Starting OSD Menu Preset... - Page 4 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà C o n f i g u r i n g R T P / R T S P Configuring the Network(TCP/IP) parameter C o n f i g u r i n g I P F i l t e r i n g Configuring HTTP Configuring UPnP/DynDNS/Bonjour C o n f i g u r i n g C M S...
-
Page 5: Introduction
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 1. Introduction ⊙ Features ■ Camera Specifications • Image Pick-up Device: 1/4" Interline Transfer CCD • Zoom Magnification: 27x Optical Zoom, 10x Digital Zoom (Max. 270x Zoom) → Model ISS2765N(P) 36x Optical Zoom, 12x Digital Zoom (Max. 432x Zoom) → Model ISS2965N(P)X •... -
Page 6: Reserved Presets For Special Purpose
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà ■ Alarm I/O Functions • 4 alarm sensor inputs and 2 alarm Output relays are available. • To reject external electric noise and shock perfectly, alarm sensor Input is decoupled with photo coupler and the relay is used for alarm output. •... -
Page 7: Product & Accessories
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 1. Introduction ⊙ Product & Accessories ■ Basic Components Optional Accessories(May vary by region) -> Adaptor ■ Other Components (available to be ordered separately) ∙Manual /CD... -
Page 8: Parts Name & Functions
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 1. Introduction ⊙ Parts Name & Functions ① Dome Cover Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust. Sets up camera ID and protocol. ②... -
Page 9: Installation
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 2. Installation ⊙ DIP Switch Setup ■ Before installing the camera, you should set the DIP switches to configure the camera ID, communication protocol. Do not use the system upgrade terminal. ■ Input Sensor Active Type •... - Page 10 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà ■ General LAN/WAN Configuration...
-
Page 11: Installation Using The Wall Mount
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 2. Installation ⊙ Installation Using the Wall Mount... -
Page 12: Installation Using The Pendant Mount
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 2. Installation ⊙ Installation Using the Pendant Mount... -
Page 13: Wire Connections
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 2. Installation ⊙ Wire Connections ■ Power Connection • The standard power for the system is 24VAC / 2A. Please, check the voltage and current capacity of rated power carefully. ■ Video Connection • Connect With BNC coaxial cable. ■... - Page 14 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 2. Installation ■ Sensor Input/Relay Output • Sensor input connection Before connecting sensors, check driving voltage and output signal type of the sensor. Since output signal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these types.
-
Page 15: Operation
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 3. Operation ⊙ Check Points before Operation • Before power is applied, please check the cables carefully. • If you changed camera protocol by changing DIP switches, the change will be effective after you reboot the camera. ⊙... - Page 16 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Figure 3-1 Log-in window...
- Page 17 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Configuring PTZ • This configures XPEED-XNET’s PTZ information, Click [▷ PTZ Configuration] to open the page shown in Figure 3-2. Figure 3-2 PTZ Configuration...
- Page 18 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description This moves the viewable area within the active CCD region. From the center, it can be moved two click positions in the the positive/negative x/y direction. Direction Key This button moves origin point. When push Tele button, camera go Zooms In.
- Page 19 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà • Configuring and operating Network PTZ This controls XPEED-XNET’s PTZ. Click PTZ button in operator mode to open the page shown in the Figure 3-3. Figure 3-3 Web Viewer Page...
- Page 20 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description This moves the viewable area within the active CCD region. From the center, it can be moved two click positions in the the positive/negative x/y direction. Direction Key This button moves origin point. When push Tele button, camera go Zooms In.
- Page 21 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà • OSD menu selection • This page setups Preset, Pattern,and Swing, and Group of PTZ general functin or select Alarm I/O using OSD menu. • OSD ON/OFF : Click Menu On/Off button in OSD menu of control group at this page. •...
-
Page 22: Preset And Pattern Function Pre-Check
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 3. Operation ⊙ Preset and Pattern Function Pre-Check • Check how to operate preset and pattern function with web viewer or CMS in advance to operate camera function fully when using web viewer or CMS. •... -
Page 23: Pattern
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà ⊙ Pattern • Function Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller and preset move functions for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern. -
Page 24: Other Functions
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 3. Operation ⊙ Other Functions • Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Pattern, Swing and Group are available fort his function but Jog actions are not available to resume. •... -
Page 25: Osd Menu
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ OSD Display of Main Screen • P/T/Z Information Current Pan/Tilt angle in degree, zoom magnification and a compass direction. • Action Title Followings are possible Action Titles and their meaning. “SET PRESET xxx” →... -
Page 26: General Rules Of Key Operation For Menu
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ General Rules of key Operation for Menu • The menu items surrounded with < > always has its sub menu. • For all menu level, to go into sub menu, press NEAR key. •... -
Page 27: Privacy Zone Area Setup
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Privacy Zone Mask Setup (Models ISS2965N(P)X and ISS2765N(P) Only) Select area in image to mask. • MASK NO [1~8] Select Mask number. If the selected mask has already data, camera moves as it was set. -
Page 28: Camera Setup(27X Iss2765N(P) Models)
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Camera Setup ( Model ISS2765N(P)) Setup the general functions of 27x optical zoom camera module. • FOCUS MODE [AUTO/MANUAL/SEMIAUTO] Sets camera focus mode. • MAX ZOOM [x1 ~ x270] Sets the maximum zoom magnification. •... -
Page 29: P R I V A C Y Z O N E M A S K S E T U
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ■ AUTO EXPOSURE SETUP • BACKLIGHT [OFF/C1/C2/L1/L2/U1/U2/D1/D2/R1/R2] Sets Backlight Compensation. The reference position and the level of BLC are selectable. Refer to the table below. Note1) • DAY/NIGHT [AUTO/DAY/NIGHT] • SLOW SHOUTTER [OFF/2~128 Field] Activates SLOW SHUTTER function when luminance of image(signal) is too dark. -
Page 30: Iss2965N(P)X
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Camera Setup ( ISS2965N(P)X ) Setup the general functions of 36x optical zoom modules. • FOCUS MODE [AUTO/MANUAL/SEMIAUTO] Sets camera focus mode. • DIGITAL ZOOM [ON/OFF] Sets digital zoom on or off. •... - Page 31 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ■ AUTO EXPOSURE SETUP • BACKLIGHT [ON/OFF] Sets Backlight Compensation. • DAY/NIGHT [AUTO/DAY/NIGHT] • AE MODE [AUTO/SHUTTER/IRIS/GAIN/BRIGHT/MANUAL] Selects automatic exposure mode. Each mode appears with adjustable values. When Flickeress mode is ON, AE mode is automatically in SHUTTER SPEED mode.
-
Page 32: Motion Setup
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Motion Setup Setup the general functions of Pan/Tilt motions. • MOTION LOCK [ON/OFF] If Motion Lock is set to ON, it is impossible to set up and delete Preset Swing, Pattern and Group. It is possible only to run those functions. -
Page 33: Preset Setup
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ■ ALARM ACTION SETUP Sets the preset to move to when the alarm is input. • ALARM N ACT [NOT USED/PRESET 1~128] Assign counteraction Preset position to each Alarm input ⊙ Preset Setup •... -
Page 34: Edit Preset Scene
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ■ EDIT PRESET SCENE ① Using Direction KEY, move camera to desired position. ② By pressing NEAR key, save current PTZ data. ③ Press FAR key to cancel. ■ EDIT PRESET LABEL ①... -
Page 35: Swing Setup
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Swing Setup • SWING NO. [1~8] Selects Swing number to edit. If a selected Swing has not defined, “NOT USED” is displayed in 1st Position and 2nd Position. • 1ST POS. [PRESET 1~128] 2ND POS. -
Page 36: Pattern Setup
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Pattern setup • PATTERN NO. [1~4] Selects Pattern number to edit. If a selected pattern number is not defined, “UNDEFINED” will be displayed under selected pattern number. • CLR PATTERN [CANCEL/OK] Deletes data in current pattern. -
Page 37: Group Setup
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ Group Setup • GROUP NO. [1~8] Selects a group number. If the selected number is not set, “UNDEFINED” will be displayed selected Group number. • CLEAR GROUP [CANCEL/OK] Clears the current setting of a group. •... - Page 38 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ④ Set up items such as Action, ###, Dwell and OPT ⑤ After finishing setting up a Action, press NEAR key to one-upper-Level Menu(Step②). Move cursor Up/Down to select Action Number and repeat Step ②~ Step ④ to edit selected Group.
-
Page 39: System Initialize
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 4. OSD Menu ⊙ System Initialize • CLEAR ALL DATA Deletes all configuration data such as display, camera, motion setup and so on. • CLR DISPLAY SET Initializes Display Configuration. • CLR CAMERA SET Initializes camera Configuration. •... -
Page 40: Ip Network Part
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ system Administration Logging On • You can log on as an administrator using either Internet browser or ‘CMS’ software. (This manual will describe about using Internet browser only.) Using Internet Explorer •... -
Page 41: Operating The Camera
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Operating the Camera When you log in as an administrator, XPEED-XNET’s Basic Setup page will appear as shown in Figure 5-1. Setup pagers for different features can be accessed from this page. Access to each feature are controlled by different user groups ( Administrator, Operator, and Viewer ). - Page 42 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà “ ● “ Accessible “ ▬ “ Not Accessible Access Function Administrator Operator Viewer Index Page ● ● ● Multi-Index Page ● ● ● PTZ Page ● ● ▬ Motion Page ● ● ▬ Users Setup Page ●...
-
Page 43: Live View
5. IP network Part ⊙ Live view (Web Viewer) When you access in IP-XNET product, Web Viewer page will appear automatically. Viewer area displays the video output from the camera, and menu bar taps that lead to each feature setting page. - Page 44 Captures the still image and displays on a pop-up window. Capture [Save to] c:\xNetCapture Opens up Basic Setup page. Setting Setup page for each IP-XNET feature can be opened from this Menu screen. (Please refer to 5-4 ~ 5-21 for detail) Opens up PTZ page.
-
Page 45: Status Window
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Status Window Status page display XPEED-XNET system’s Version and its Ethernet address. Clock [▷ Status] button to open the page shown in Figure 5-4. Figure 5-4 Status Page (Internet Explorer 7.0) - Page 46 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà MEMO...
-
Page 47: Configuring Users
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Users This can give or limit authority to users for controlling Video and other features of XPEED-XNET system. Click [▷ Users] button to open the page shown in Figure 5-5. Figure 5-5 Users Configuration Page... - Page 48 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Displays list of registered users. User List "root" is the system’s administrator. "root" cannot be added or deleted. Only the password for “root” can be changed. This adds a new user. Select “[Add_User]”...
-
Page 49: Setting Date & Time
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Setting Date & Time This page will change Date and Time of XPEED-XNET system. Click [▷ Date & Time] to open the page shown in Figure 5-6. Figure 5-6 Date and Time Page... - Page 50 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Current Server Time Displays time of XPEED-XNET system. Time Zone Selects Time Zone. <Default : GMT+09> Enable Daylight Enables/Disables Daylight Saving Time. Time New Server Time Sets Date and Time of the Server. <Default : None>...
-
Page 51: Configuring Multi Viewer
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Multi-Viewer Up to 3 cameras connected to XPEED-XNET’s network can be displayed as sub-cameras simultaneously in Multi-View page. Click [▷ Multi Viewer] to copn the page shown in Figure 5-7. Figure 5-7 Multi-Viewer Configuration Page... - Page 52 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enables viewing of 1st sub ChannelVideo from IP address entered. Enable 1st This can only be enabled when IP address, User Name, Sub Channel Video and Password is properly entered. <Default : Disable> 1st Sub-Channel 1st IP Address Enter 1st Sub Channel’s IP Address.
-
Page 53: Configuring Ptz
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuration PTZ This configures XPEED-XNET’s PTZ server information. Click [▷ PTZ Configuration] to open the page shown in Figure 5-8. Figure 5-8 PTZ Configuration page... - Page 54 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà This moves the viewable area within the active CCD region. From the center, it can be moved two click positions in the the positive/negative x/y direction. Direction Key This button moves origin point. When push Tele button, camera go Zooms In. Tele/Wide When push Wide button, camera go Zooms Out.
-
Page 55: Maintaining Server
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Maintaining Server Configurations This page configures system parameters such as system restart, factory default settings, system upgrade, Saving configurations, saving images, and other additional features. Click [▷ Maintain Server] to open the page shown in Figure 5-9. Figure 5-9 Server Maintenance page... - Page 56 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Restart Restarts the system. It takes about 45 seconds. Maintain Resets all parameters except for TCP/IP settings. Light Default Server This restore will be followes by about 45 seconds system reset. Resets all parameters to Factory Default setting.
-
Page 57: Generating Log Report
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Generating Log Report Log report contains detailed information about XPEED-XNET’s image,setup, and error. Click [▷ Log Report] button to open the pageshown in Figure 5-10. Figure 5-10 Log report page... - Page 58 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description System Settings System Overview Displays current configurations for XPEED-XNET option pages. Loads up Log Messages file stored in the XPEED-XNET product. Load List Log Message file can be sorted with date and index. Click Load List button to view messages list in the Listbox.
-
Page 59: Configuring Audio
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Audio XPEED-XNET’s Audio features can be configured in this page. Click [▷ Audio] button to open the page shown in Figure 5-11. Figure 5-11 Audio configure page... - Page 60 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Audio Enables or disables Audio feature. Enable audio Enable <Default : Disable> Select audio input source between Microphone and line<Default : Microphone>. Microphone input can be used when users send their voice over XPEED-XNET system. Line Source Audio input takes the input from an audio device to send over XNET.
-
Page 61: Configuring Video
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Video XPEED-XNET’s video features can be configured in this page. Click [▷ Video] button to open the page shown in Figure 5-12. Figure 5-12 Video configure page... - Page 62 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Select a resolution of the video image. Resolution D1 <Default : D1> Select Video Codec. Codec Main Stream Select among MJPEG , MPEG4, and H.264. Turns Sub Stream feature on or off. <Default : Disable> Enable Sub Stream output is in MJPEG with maximum 15 frame per second.
-
Page 63: C O N F I G U R I N G R T P / R T S
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring RTP/RTSP This is related to XPEED-XNET’s DDNS server information. Click [▷ RTP/RTSP] to open the page shown in Figure 5-13. 그림 1-14 카메라 설정 페이지 Figure 5-13 RTP/RTSP page... - Page 64 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enter RTSP Port of the Main Stream between 1 and 65535. RTSP Port The default is 554. RTSP Configuration Multiple-RTSP Port Enter RTSP Port of the Sub Stream between 1 and 65535. The default is 665. Enter RTP Start Port between 1024 and 65534.
-
Page 65: Configuring The Network(Tcp/Ip) Parameter
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring the Network(TCP/IP) parameters This configures XPEED-XNET’s network related parameters. Click [▷ TCP/IP] button to open the page shown in Figure 5-14. Figure 5-14 Network Setup page... - Page 66 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Turns DHCP on or off. Check DHCP checkbox to get an IP address automatically from the network using DHCP Enable DHCP protocol. Obtained IP address can be viewed by IP Installer. (default) (Note) If the network does not use DHCP server, the product will wait for server’s response for two minutes and restart with its previous IP address.
-
Page 67: C O N F I G U R I N G I P F I L T E R I N
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring IP Filtering This configures IP Filters for XPEED-XNET product. Click [▷ IP Filtering] button to open the page shown in Figure 5-15. Figure 5-15 IP filtering Page... - Page 68 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Filter IP List Displays list of currently established IP Filters. Adds an IP address to filter out. Enter the IP Address to block and click add button to add it to IP Filtering listbox. The updated list can be viewed in IP Address Listbox.
-
Page 69: Configuring Http
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring HTTP This configures HTTP port to access XPEED-XNET’s webpage. Click [▷ HTTP] button to open the page shown in Figure 5-16. Figure 5-16 HTTP Page... - Page 70 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enter HTTP Port to access the webpage. Default port is 80, and any other port number has to be entered at the end of the ip address HTTP HTTP port when accessing. (Ex: When using HTTP Port 8080, enter http://192.168.123.100:8080) Save Applies and saves changes.
-
Page 71: Configuring Upnp/Dyndns/Bonjour
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring UPnP/DynDNS/Bonjour UPnP is a protocol for IP installer software. You can enable or disable this UPnP, and you can also use a Friendly Name. DynDNS configures XPEED-XNET’s DDNS server information. Click [▷... - Page 72 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enables or disables UPnP. Enable UPnP UPnP When enabled, you can use IP Installer’s XNET Auto Search feature. Setting Friendly Name Enter UPnP’s Friendly Name. Enables or disables DynDNS. Enable DynDNS When enabled, you can automatically obtain a domain from DDNS server by simply registering the XNET product.
-
Page 73: C O N F I G U R I N G C M
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring CMS This configures XPEED-XNET’s CMS server infomation. Click [▷ CMS] to open the page shown in Figure 5-18. Figure 5-18 CMS Page... - Page 74 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enter CMS port number for communication with CMS between 1 and 65535. The default is CMS Port 5000. Save Applies and saves changes. Reset Recalls previously saved configurations.
-
Page 75: C O N F I G U R I N G E V E N T T Y P
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Event Type This is related to XPEED-XNET’s DDNS Server information. Click [▷ Event Types] to view page shown in Figure 5-19. Figure 5-19 Event Types page... - Page 76 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enables or disables event processing. <Default : Disable> <Note for users> Event Enable Enable Event When this is enabled in the D1 Mode, the transmitted fame rate is reduced by up to 15 fps.
-
Page 77: S M T P S E T U
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ SMTP Setup This configures mailing out method of alarm Images once event occurred in the XPEED-XNET system. Click [▷ SMTP] button to open the page shown in Figure 5-20. Figure 5-20 SMTP Page... - Page 78 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Turns Internal SMTP Server on or off. Enable When this box is checked, Alarm Image gets mailed out through an internal mail server. Mail Internal SMTP Authentication cannot be used in this mode. Server When this box is unchecked, Alarm Image gets mailed out through an external mail server.
-
Page 79: C O N F I G U R I N G F T
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring FTP This configures How the Alarm Images get sent out using FTP once event occurred in the XPEED-XNET system.. Click [▷ FTP] button to open the page shown in Figure 5-21. Figure 5-21 FTP Page... - Page 80 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Enter the address of the FTP server to send Alarm Images to in the event processing. FTP Name The client PC at that IP address has to run the FTP server in order to receive the Alarm Images.
- Page 81 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring and operating Network PTZ This controls XPEED-XNET’s Speeddome PTZ. Click PTZ button in Operator mode to open the page shown in Figure 5-22. Figure 5-22 PTZ page...
- Page 82 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description This moves the viewable area within the active CCD region. From the center, it can be moved two click positions in the the positive/negative x/y direction. Direction Key This button moves origin point. When push Tele button, camera go Zooms In.
-
Page 83: C O N F I G U R I N G M O T I O N D E T E C T I O N A R E
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Motion Detection area This defines area that detect motion, and up to three different areas can be defined in each channel. Click Motion button in Operator mode to open the page shown in Figure 5-23. Figure 5-23 Motion Detection Page... - Page 84 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà Field Sub Field Description Displays currently defined Motion Detection area. Area When an area is selected from the list, its defined area gets displayed and highlighted in viewer window. Up to 3 motion detection area can be defined. Show selected area When this is checked, only the selected area gets displayed in viewer window.
-
Page 85: Configuring Multi View Option
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 5. IP network Part ⊙ Configuring Multi View Option This configures viewing of up to 4 different camera images simultaneously.. Click button in Administrator mode to open the page shown in Figure 5-24. The video from the XPEED-XNET product gets displayed on top left, and the rest display video signals coming from the IP addresses defined in the Multi-viewer Setup page. - Page 86 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà MEMO...
-
Page 87: Specifications
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 6. Specifications ⊙ 27x Models (ISS2765N(P)) ■ Types by installation Video Signal NTSC Image Pick-up Device 1/4” SONY Super HAD CCD Effective Pixels 811(H) x 508(V) 410K 795(H) x 596(V) 470K Horizontal Resolution 768(H) x 494(V) 380K 752(H) x 582(V) 440K Resolution 480 TV Line... -
Page 88: Iss2965N(P)X) Exview Models
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 6. Specifications ⊙ 36x EXview Models (ISS2965N(P)X) ■ Types by installation Video Signal NTSC Image Pick-up Device 1/4” SONY EXview HAD CCD Effective Pixels 768(H) x 494(V) 380K 752(H) x 582(V) 440K Horizontal Resolution 530 TV Lines S/N Ratio 50 dB (Weight ON) Zoom... -
Page 89: Dimensional Drawings
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 6. Specifications ⊙ Dimensional Drawings unit (mm) - Page 90 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 6. Specifications ⊙ Dimensional Drawings Unit (mm)
-
Page 91: System Models And Related Accessories
bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà 7. System Models & Related Accessories ⊙ System Model Numbers 27x Day/Night(ICR) 36x Day/Night(ICR) Type / Image Super HAD CCD EXview HAD CCD IS2765NW IS2965NXW IS2765PW IS2965PXW IS2765NP IS2965NXP IS2765PP IS2965PXP ISS2765NW ISS2965NXW ISS2765PW ISS2965PXW ISS2765NP ISS2965NXP ISS2765PP... - Page 92 bâàwÉÉÜ fÑxxw WÉÅx fxÜ|xá |Ñ@åÇxà MEMO...
