- Page 1 Ver. 1.1 XNET Network Dome Camera (IDP4000VR/IDP4000VD/IVP4000VR) Installation Manual...
-
Page 2: About This Manual
About this Manual A compatibility and durability test ensured this product’s high performance. This manual is for XNET Network Dome Camera users only, and it describes operations related to XNET Network Dome Camera. Please read this manual thoroughly paying attention to cautions and warnings before using the product even if you have used similar products before. -
Page 3: Table Of Contents
Index 1. About XNET ........................4 1.1. About XNET ..........................4 1.2. Features of XNET ........................4 1.3. Applications ..........................4 2. About the Product ......................5 2.1. Contents ........................... 5 2.2. Product Information ........................5 2.3. Hardware Designation ......................6 2.3.1. -
Page 4: About Xnet
1. About XNET XNET is an internet based security and surveillance system that is compatible with various network conditions through easy installation and user interface as well as multi-functional compressor Codec such as MJPEG, MPEG-4, and H.264. XNET provides stable real-time surveillance by real time video/ audio at VGA level, local storage for any network problems, and hybrid IP technology that can be used with existing analog CCTV devices. -
Page 5: About The Product
2. About the Product Please make sure the following contents are included when you open the package Contents Description Additional info. XNET XNET Network Dome Camera AC Power Cable 2Jack Cable Terminal Terminal for Alarm and Audio Software and User’s manual Install CD XNET Viewer Program... -
Page 6: Hardware Designation
This shows Camera module inside the dome cover. Mic/Audio Input Audio Output Alarm Input/Output Analog Video Output Network Power Terminal Zoom Adjust Factory Reset button Recalls factory default Focus Adjust configurations CDS Sensor IR LED This CDS Sensor detects Low Light (night) and turns on IR LEDs. -
Page 7: Connecting Cables
Power Supplies Power to the Xnet product. Use 12V DC Adapter in the package. Do not use this connector when powering up the product through LAN cable. (PoE) The product is not covered under warranty when it is damaged by connecting both Ethernet power and 12V DC power to this terminal. -
Page 8: Connecting To Alarm Devices
Network Terminal This Ethernet terminal connects to 100Mbps LAN through an RJ-45 connector. When optional PoE is used, the power will be supplied from the Network Cable. Link LED Yellow light indicates that the network is properly connected. Act LED Green light indicates that the XNET system connected to 100Mbps LAN. -
Page 9: Software Installation
3. Software Installation This section provides brief guidelines to install the XNET quickly and to monitor XNET’s Video and Audio signals easily. If you have questions about details not explained in this section or if the product is not functioning as described, please refer to FAQ before contacting the store. Mount the Camera to a ceiling or a wall. -
Page 10: Cable Connection
Adjust the position, zoom, and focus as shown below: TILT : 90˚ FOCUS Horizontal ZOOM Rotation : 360˚ PAN : 360˚ 1.A PC or a laptop computer is required to set up an IP address. Compatible operating system: Windows 2000/ Windows XP/ Windows Vista Since the default IP address of the device is 192.168.123.100, set up the IP address of the computer like the following: IP Address : 192.168.123.101 Subnet Mask : 255.255.255.0... -
Page 11: Installing Ip-Installer Software And Configuring Ip Address
A unique IP address has to be configured in order to connect IP camera and monitoring PC to a network. IP- Installer software provided in the Installation CD (included in the package) will configure IP address easily. If your network have a DHCP server that automatically assigns IP addresses to IP cameras. If your network does not have a DHCP server, the default IP address of the device is 192.168.123.100. - Page 12 2. Select the camera of which you wish to change the IP address and click (Set IP Address) button to bring up the following box in Figure 3-3. Figure 3-3. IP Address box 3. When you enter the IP address and click Set button, the box shown in Figure 3-4 will appear. Figure 3-4.
-
Page 13: Using Web Viewer
4. Using Web Viewer Connecting to network devices can be done using internet web browser or “XNET-CMS” software. This guide explains about using internet web browser only. For instructions on how to configure network connection using XNET-CMS software, please refer to XNET-CMS Manual, which can be found in the installation CD. -
Page 14: Web Viewer Page
Web viewer page consists of Video monitor screen and menu option buttons. Figure 4-2 Web Viewer Page 14 / 17... - Page 15 Item Sub Item Description Captures and saves the current image as a still picture. Capture The image is saved as jpeg file in the following folder: C:₩xNetCapture Brings up Menu screen. Setup page for each XNET feature can be opened from this Menu screen. Setting Please refer to [XNET Owner’s Manual] for detail.
-
Page 16: Specification
Specification IxP4000 Specifications Signal System Progressive image processing Scanning System 4:3 Progressive Image Sensor Progressive CCD Sensor Sync. System Internal Effective Pixels Number 659 (H) x 494(V) 330K Video Output Level Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite) Lens Built-in DC Iris Vari-focal Lens, f=3.8~9.5mm, F1.2 Back Light Compensation On/Off Flickerless... - Page 17 Web Viewer (Window Web Browser Base) Live view for up to 10 user clients Monitoring Application Video Snapshot to file (JPEG) NVR, CMS and Utility (IP-Installer, etc) System Upgrade Firmware upgrade over HTTP Maintenance PTZ control (RS-485) PTZ Protocol Service (User define update) Operating Temperature ~ 40 ℃...
