Preparing the Cable Cubby
Step 1 (Only for multiple enclosures) — Assemble Enclosures
1
Using a #2 screw driver,
unscrew the four pan-head
screws that attach the enclosure
sides of the Cable Cubby together.
Repeat this step on the corresponding
side of the other enclosure.
Detach side panels of both enclosures.
Step 2 — Assemble Connectivity Modules
Connectivity modules allow you to populate the Cable Cubby enclosure with a combination of AAPs, cable pass-through, or
Retractors. Follow the steps below to assemble the connectivity modules of your choice.
Option 1: AAP Module
1
Secure up to three single-space
AAPs in the AAP plate.
#4-40 Nut with
Captive Washer
Option 2: Cable Pass-Through Module
1
Insert cables through the
bottom of the connectivity
bracket and into the holes
of the grommet plate.
2
Secure the grommet
plate on the connectivity
bracket, using four of the
provided module screws.
4
3
Repeat steps 1 and 2 to
add more enclosures to
the extension.
3
Secure the AAP plate on the connectivity brackets,
using four of the provided module screws.
2
Insert cables through the bottom of the connectivity bracket.
Connect cables to the AAPs.
Option 3: Retractor Bracket
NOTE:
1
2
Secure the bracket using four of
the provided pan-head mounting
3
screws with star washers. Tighten
the screws using a screwdriver.
Snap the included
hole plugs into
any unused holes.
Before attaching the enclosure, ensure the
keyhole mounting holes are orientated in the
same direction.
2
Attach the enclosures together
with the four pan-head mounting screws
and washers that were removed in step 1.
The opening of the bracket should be
installed towards the outside of the enclosure.
2
Insert "Show Me"
Attach the "Show Me" Cable Trim Plate
Cables into the
to the top of the module, using the
grommet plate.
module screws.
3
Attach the grommet
plate to the bottom
1
of the module, using
the module screws.
Insert the bracket as shown.
The bracket may be installed on the left
left
or right side of the enclosure and at the
the
lowest height.
