Advantech MIC-3321 Startup Manual page 3

Software Configuration
Overview
MIC-3321 has a CD-ROM with utilities and drivers.
Please install the Chipset INF driver, VGA graphics
driver, and LAN driver.
Utilities and Drivers
The following utilities and drivers are provided with the
MIC-3321 series. You can also find updated description
of the utilities and drivers in the ReadMe.txt file on the
CD-ROM.Windows 2000/XP are fully supported by
the MIC-3321 series.
Intel Chipset Software Installation Utility
Path: Driver\Inf\I915GM
Available for the operating systems listed below:
• Microsoft Windows 2000
• Microsoft Windows XP
Intel VGA Graphics Driver
Path: Driver\VGA\915GM\
Available for the operating systems listed below:
• Microsoft Windows 2000
• Microsoft Windows XP
Intel Gigabit LAN Driver
Path: \Driver\Lan\82573E\
Available for the operating systems listed below:
• Microsoft Windows 2000
• Microsoft Windows XP
Pin Assignments
This chapter shows the pin assignments of MIC-3321
series CPU cards.
J1 & J2 Connectors
Table 1.1: J1 Connectors
Pin A B
25 5V REQ6
4#
24 AD1 5V
23 3.3V AD4
22 AD7 GND
21 3.3V AD9
20 AD12 GND
19 3.3V AD15
18 SERR# GND
17 3.3V N/C
16 DEV- GND
SEL#
15 3.3V FRAM
E#
12~ KEY
14
11 AD18 AD17
10 AD21 GND
9 C/BE3# N/C
8 AD26 GND
7 AD30 AD29
6 REQ0# N/C
5 N/C N/C
4 N/C GND
3 INTA INTB
2 TCK 5V
1 5V -12V
V(I/O):PCI buffer voltage form backplane
#: Low active
Startup Manual 3
C D E
ENUM# 3.3V 5V
V(I/O) AD0 ACK64# GND
AD3 5V AD2
3.3V AD6 AD5
AD8 GND C/BE0#
V(I/O) AD11 AD10
AD14 GND AD13
3.3V PAR C/BE1#
N/C GND PERR#
V(I/O) STOP# LOCK#
IRDY# GND TRDY#
AD16 GND C/BE2#
3.3V AD20 AD19
AD23 GND AD22
V(I/O) AD25 AD24
AD28 GND AD27
3.3V CLK0 AD31
PCI_RS GND GNT0#
T#
V(I/O) N/C N/C
INTC 5V INTD
TMS TDO TDI
TRST# 12V 5V
F
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
