MIC-1816R
16-Bit, 1 MS/s DAQ Platform with NXP ARM®
Cortex®-A9 i.MX6 1 GHz Processor
Startup Manual
Packing List
Before installation, please ensure that the following items
have been included in your shipment:
1. 1 x MIC-1816R system
2. 1 x Adapter 100 ~ 240 V 36 W 12 V without PFC
DC plug 90°
3. 1 x MIC-1816R startup manual
4. 1 x User note for MIC-1816R
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Caution: BATTERIES ARE AT RISK OF EXPLODING IF
INCORRECTLY REPLACED. REPLACE ONLY WITH
THE SAME OR EQUIVALENT TYPE RECOMMEND-
ED BY THE MANUFACTURER. DISCARD USED
BATTERIES ACCORDING TO THE MANUFAC-
TURER'S INSTRUCTIONS.
Attention: DANGER D'EXPLOSION SI LA BATTERIE EST
INEXACTEMENT REMPLACÉE. REMPLACEZ
SEULEMENT AVEC LA MÊME CHOSE OU LE TYPE
ÉQUIVALENT RECOMMANDÉ PAR LE FABRICANT,
JETTENT LES BATTERIES UTILISÉES INSTRUC-
TIONS DE S SELON FABRICANT DES'.
For more information about this or other Advantech
products, please visit our website at
http://www.advantech.com
http://www.advantech.com/Products
For technical support and customer service, please
visit our support website at
http://support.advantech.com.tw/support/default.
aspx
This manual is for the MIC-1816R Series.
Part No. 2041181600
Printed in Taiwan
Specifications
System
• NXP ARM
Memory
• 4 GB DDR3 memory and eMMC onboard
Graphics
• HDMI 1920 x 1080 @ 60 Hz
Serial Ports
• 2 x RS-232 from COM1/COM2
• 2 x CAN from CAN1/CAN2
Ethernet
• Interface: 10/100/1000 Mbps
• Controller: NXP i.MX6-integrated RGMII
Storage
• Internal SSD: 1 x 2.5" SSD bay
Front I/O
• USB: 1 x USB 2.0 and 1 x USB 2.0 OTG
Power Requirement
• Power Type: DC power jack
• Input Voltage: 12 V
Miscellaneous
• Power Switch
Orange: System standby
Green: System boot
Mount Kit (Optional)
• Table Mount: 1960077844N001; 130 x 175 mm
• DIN Rail Mount: 1960018849T001
Environment
• Operating Temperature: -10 ~ 60 °C/14 ~ 140 °F with
0.7m/S air flow and 1 x industrial SSD
• Relative Humidity: 95% @ 40 °C (non-condensing)
Physical Characteristics
• Dimensions (W x H x D): 165 x 130 x 66 mm (6.49 x
5.11 x 2.59 in)
• Weight: 1.05 kg (2.32 lb)
Edition 1
April 2019
Cortex
-A9 i.MX6 high-performance processor
®
®
DC
MIC-1816R Startup Manual 1
