Foil Threading - Open Date EUROCODE 150 Operator Instructions Manual

Eurocode Digi50 Controller V1.03
MAGAZINE REMOVAL (refer to page 38)
To remove the foil magazine, slide the catch away from the type holder access door,
hold in place and withdraw the magazine using the two handles. Press off the PRINT
switch to silence the audible alarm.
FOIL THREADING (refer to pages 9 & 38)
1. Fit an empty foil core onto the rewind mandrel.
2. Disengage the pinch drive roller.
3. Remove label from a new roll of foil.
4. Fit new roll of foil onto take-off mandrel (note unwind direction as shown on
threading diagram).
5. Thread foil around all rollers as shown on threading diagram. Note, the gloss
side of the foil should face inwards throughout the foil path.
6. Attach end of foil to empty core on rewind mandrel, gloss side facing inwards.
7. Wind foil on a few turn to track and tension it.
8. Engage pinch drive roller.
RE-FITTING FOIL MAGAZINE
Hold the magazine by the two handles, slide in onto the locating pins and push to lock
in place. Press the PRINT switch on.
FITTING TYPE/DIE HOLDER
"Never assume that a Type/die holder is cold"
Only pick up a type/die holder by its handle. Ensure that the face of the magnetic catch
is clean, open the red type holder access door (the alarm will sound unless the print
switch is off), align the type/die holder within the two side locators and slide in until the
magnet catches on the end plate. Close the door.
FOIL FEED ADJUSTING SCREW
This is used to adjust the amount of foil used per print, winding it in reduces the foil pull.
Ensure that the locking nut is fully tightened after adjustment. A gap of 1 or 2mm is
recommended between each section of used foil.
04/07/2005
OPERATING INSTRUCTIONS
(refer to page 38)
Page - 8 -
