Open Date EUROCODE 150 Operator Instructions Manual page 19

Eurocode Digi50 Controller V1.03
Trigger/Print Signal - Grey twin core screened
See page 39 for details of "Input Print Signals"
P+. Red
P-. Black
Solenoid Valve - Black twin core.
S+ Red
S-. Blue
Printer – Multi-Core screened to 9 pin D plug.
D2. Mauve
D1. Brown
F2. Pink
F1. Black
PM. White
T. Green
T. Yellow
H. Red
H. Blue
Mains Cable - Three core white.
N. Blue
L. Brown
E. Yellow/Green
04/07/2005
Connection Details - Row "c"
External trigger input. + volts connection.
External trigger input. – volts connection.
Solenoid output. + volts connection.
Solenoid output. – volts connection.
Type Holder door safety switch return.
Feed to the safety switch & foil sensor, –0v DC.
Feed to the foil sensor, +14v DC.
Output from the foil sensor.
Foil sensor Printmaster only.
Thermistor connection.
Thermistor connection.
Heater element.
Neutral ac heater element.
Neutral.
Live.
Earth.
Page
.
D plug Connections.
Pin 6
Pin 5
Pin 9
Pin 8
Pin 7
Pin 2
Pin 1
Pin 3
Pin 4
