Open Date EUROCODE 150 Operator Instructions Manual page 40

Eurocode Digi50 Controller V1.03 04/07/2005 Page - 40 -
Specifications for Digi50 Controller
Supply Voltage
Nominal 230v AC, plus or minus 10% tolerance (207 – 253). 50 or 60 Hertz.
Nominal 115v AC, plus or minus 5% tolerance (109 – 121). 50 or 60 Hertz.
Heater
Maximum 4 Heaters. (240 Volt 250 Watt)
Thermistor (Standard)
Model No. G55W (Part No. THE 500502)
Output Relay Contacts
Fault Relay:- Rated at 24V DC, 1 amp current.
Print Relay:- Rated at 24V DC, 1 amp current.
(both relays utilise common, normally open or normally closed contacts)
Input Print Signals
Voltage Free contacts. (relay or plc etc.)
Voltage 10 – 30 Volts AC or DC (polarity unimportant)
Microproccessor
PIC Micro-Processor.
Controlled by a specific designed membrane panel with inbuilt switches etc.
The temperature display, is seen through a translucent red panel on the membrane.
Solenoid Valve Output
24 Volt DC, 80mA current normally.
(Part No's VAL 400017 or VAL 400018 or VAL 400021)
A maximum of 2 Solenoid Valves (Opendate Supplied) can be driven by the Controller.
(Maximum current available 200mA)
