Low Air Pressure Option - Open Date EUROCODE 150 Operator Instructions Manual

Eurocode Digi50 Controller V1.03
Note.
The low air pressure switch connections are to Air Switch "A" and "B" and can be found on the
terminal board mounted in the rear section of the enclosure. (See Below)
COM
N/O
Air Switch Not Supplied
Adjust the Air Pressure Switch to suit the application.
See specification sheet to suit the printer, should be in the front of this manual.
Ensure the Dip Switch settings are correct. (See below)
Low Air Configuration SW2 (No 3)
Disabled
04/07/2005
Digi50 Low Air Pressure Option
AIR PRINT
SWITCH RELAY
OMRON
G5V-1
24VDC
FAULT
RELAY
T T PM F1 F2
Page
L N E
D1 D2 S- S+ P- P+
Enabled
