Eurocode Digi50 Controller V1.03
04/07/2005
Page
- 12 -

SOLENOID VALVE DETAILS

RED PIPE
BLACK PIPE
TO PRINTER
TO PRINTER
SOLENOID VALVE
FIXING HOLES
MOUNTING
LOCK NUT
PLATE
AIR FLOW RESTRICTOR
AIR FLOW RESTRICTOR
(for forward stroke)
(for return stroke)
SILENCERS
