Open Date EUROCODE 150 Operator Instructions Manual page 32

Eurocode Digi50 Controller V1.03
EUROCODE MECHANICAL PARTS LIST (continued)
ITEM DESCRIPTION
58 Roller
59 Grub screw
60 Main body
61 Piston
62 Bottom cap
63 Databox packing
64 Guide pin
65 Washer
66 Needle Bearing
67 Spindle
68 Spring
69 Cam
70 Mounting plate
71 Lock nut
72/73 Foil adjusting screw assy
74 Dowel pin
75 Plug housing
76 Drive spindle
77 Strike plunger
78 Timing pulley
79 "O" ring
80 Rod seal
81 Microswitch support
82 Nose bearing
83 Piston seal
84 Bush
85 Microswitch
86 Clutch Bearing
87 Needle bearing
88 Cap screw
89 "O" ring
90 Timing belt
91 Roll pin
92 Cap screw
93 Grub screw
94 Button screw
95 Lock nut
96
97
98
99 Needle bearing
100 Dowel pin
101 Cap screw
102 Cap screw
103 Cheese head screw
104
105 Grub screw
106 CSK screw
107 Side locator
108 Cushion
109 Location pin
110 lever
111 Timing pulley assy
112 Magnet
113 Roller
114 Insulating plate
115 Heater block
116
117 Mounting screw
118 Keep plate
119 Button screw
120 Cover
121 Fork end assy
122 Cap screw
04/07/2005
STOCK REF QTY
ROL620018 6
1
N/A 1
PIS620020 1
N/A 1
PAC190028 1
PIN620022 1
WAS620065 1
BEA521008 1
SPI620059 1
SPR530033 1
CAM620025 1
PLA620026 1
NUT620027 1
ADJ620207 1
2
HOU130023 1
SPI620029 1
PLU620036 1
PUL620030 1
O-R512005 1
SEA512038 2
SUP620031 1
BEA620070
SEA512036 1
BEA520017 1
SWI395010 1
BEA521507 1
BEA521001 1
2
O-R512030 1
BEL522512 1
1
4
1
10
1
BEA520018 1
1
2
4
2
1
2
SID120014 2
DAM120074 2
LOC620032 2
LEV620110 1
PUL620219 1
MAG531001 1
N/A 1
INS120012 1
HEA120013 1
SCR120070 2
KEE120030 1
4
COV620034 1
FOR620208 1
1
Page
NOTES
M4x5
Piston/Seal assy ref. PIS620200
Part of Spring Set.
Includes item 91.
3 dia x 10
Part of Seal Kit.
Part of Seal Kit.
Part of Seal Kit.
M4x30
Part of Seal Kit.
3 dia x 20
M6x20
M5x8
M4x8
M10
M3x25
M4x45
M2x10
M8x8
M3x6
Includes item 86.
Part of item 121.
M5x8
Includes items 100,113.
M4x12
- 32 -
