Open Date EUROCODE 150 Operator Instructions Manual page 33

Eurocode Digi50 Controller V1.03
EUROCODE MECHANICAL PARTS LIST (continued)
ITEM DESCRIPTION
123 Bearing
124 Bush
125 Keep plate
126 CSK screw
127 Thumb plate
128
129 Locking plate
130 Cap screw
131 Spring
132 Grub screw
133 Plug
SUPPLEMENTARY LIST FOR EUROCODE 300 ITEMS ONLY.
ITEM DESCRIPTION
2c Rewind hub assy
135 Magazine Plate
136 Foil Guide
137 Drive Belt
138 Brake Strap
147 Hub Spindle
148 Clutch Bearing
149 Drive Boss
SUPPLEMENTARY LIST FOR EUROCODE 180 ITEMS ONLY .
ITEM DESCRIPTION
25 Drive Belt
150 Magazine Plate
ADDITIONAL SPARE PARTS AND REPAIR KITS
PNEUMATIC
Solenoid valve without fittings.
ELECTRONIC
Cartridge heater, 240v, 250w.
Thermistor probe.
Safety microswitch.
"End of foil alarm" sensor.
Plug-in Digi50 control card, 240v, box mount (horizontal).
Plug-in Digi50 control card, 115v, box mount (horizontal).
REPAIR KITS
Seal kit containing all seals.
Spring set containing all springs and drive belt (Eurocode 150).
Spring set containing all springs and drive belt (Eurocode 300).
Spring set containing all springs and drive belt (Eurocode 180).
04/07/2005
STOCK REF QTY
BEA620064 1
BUS620035 1
CAT620125 1
3
THU620127 1
LOC620129 1
2
SPR530032 1
1
PLG620037 2
STOCK REF QTY
HUB620203 1
N/A 1
GUI620040 1
DRI620049 1
BRA620051 1
SPI620147 1
BEA521505 1
DRI620149 1
STOCK REF QTY
DRI620048 1
N/A 1
NOTES
M4x10
M4x20
Part of Spring Set.
M3x8
NOTES
Includes items 42,44,50,54,148,149.
Part of Spring Set.
NOTES
Part of Spring Set.
STOCK REF
VAL510524
HEA501506
THE500502
SWI395011
ALA395018
CPC293502
CPC293503
SEA620209
SPR620216
SPR620217
SPR620215
Page - 33 -
