7.4.19 Pass Module Time to Processor Block (9973)

Block 9973: Pass Module Time to Processor Block
This block uses the time information from the module to set the processor time.
Block 9973: Request from Processor to Module
Offset Description
0 Write Block ID: 9973
1 to (n-1) Spare
Where n = 60, 120, or 240 depending on the Block Transfer Size parameter.
Block 9973: Response from Module to Processor
Offset Description
0 Read Block ID: 9973
1 Write Block ID: To be used by the processor in its next Write block.
2 Year (0-9999)
3 Month (1-12)
4 Day (1-31)
5 Hour (0-23)
6 Minutes (0-59)
7 Seconds (0-59)
8 Milliseconds
9 to (n-1) Spare
