MVI69E-MBS ♦ CompactLogix Platform
Modbus Serial Enhanced Communication Module
7

Reference

In This Chapter


Product Specifications ......................................................................... 103


About the Modbus Protocol ................................................................. 104

Floating-Point Support ......................................................................... 117

Function Blocks ................................................................................... 124

Ethernet Port Connection .................................................................... 145

Modbus Application Port Connection .................................................. 146
7.1 Product Specifications
The MVI69E-MBS allows Rockwell Automation
®
1500-LRP I/O compatible processors to interface easily with other Modbus
protocol compatible devices.
The module acts as an input/output communications module between the
Modbus network and the CompactLogix or MicroLogix 1500-LRP backplane. The
data transfer from the CompactLogix or MicroLogix 1500-LRP processor is
asynchronous from the actions on the Modbus network. Databases are user-
defined and stored in the module to hold the data required by the protocol.

Single-slot, 1769 backplane-compatible

The module is recognized as an Input/Output module and has access to
processor memory for data transfer between processor and module.

Ladder Logic is used for data transfer between module and processor.
Sample Add-On Instruction file included.

Configuration data obtained from and stored in the processor.

Supports CompactLogix or MicroLogix 1500-LRP processors with 1769 I/O
bus capability and at least 500 mA of 5 VDC backplane current available.
ProSoft Technology, Inc.
June 28, 2017
®
CompactLogix or MicroLogix
Reference
User Manual
Page 103 of 154
