Texas Instruments TMS320F28004x Technical Reference Manual page 288

Registers
Table 2-144. B1_Z2_EXEONLYSECTR Register Field Descriptions (continued)
Bit Field
11 EXEONLY_SECT11
10 EXEONLY_SECT10
9 EXEONLY_SECT9
8 EXEONLY_SECT8
7 EXEONLY_SECT7
6 EXEONLY_SECT6
5 EXEONLY_SECT5
4 EXEONLY_SECT4
288
System Control
Type Reset Description
R 0h
Value in this field gets loaded from
B1_Z2OTP_EXEONLYSECT[11:11] when a read is issued to
B1_Z2OTP_EXEONLYSECT address location in USER OTP of
Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 11 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 11 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from
B1_Z2OTP_EXEONLYSECT[10:10] when a read is issued to
B1_Z2OTP_EXEONLYSECT address location in USER OTP of
Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 10 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 10 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from B1_Z2OTP_EXEONLYSECT[9:9]
when a read is issued to B1_Z2OTP_EXEONLYSECT address
location in USER OTP of Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 9 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 9 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from B1_Z2OTP_EXEONLYSECT[8:8]
when a read is issued to B1_Z2OTP_EXEONLYSECT address
location in USER OTP of Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 8 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 8 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from B1_Z2OTP_EXEONLYSECT[7:7]
when a read is issued to B1_Z2OTP_EXEONLYSECT address
location in USER OTP of Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 7 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 7 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from B1_Z2OTP_EXEONLYSECT[6:6]
when a read is issued to B1_Z2OTP_EXEONLYSECT address
location in USER OTP of Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 6 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 6 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from B1_Z2OTP_EXEONLYSECT[5:5]
when a read is issued to B1_Z2OTP_EXEONLYSECT address
location in USER OTP of Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 5 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 5 (only if it's
allocated to Zone2)
R 0h
Value in this field gets loaded from B1_Z2OTP_EXEONLYSECT[4:4]
when a read is issued to B1_Z2OTP_EXEONLYSECT address
location in USER OTP of Flash BANK1.
0 : Execute-Only protection is enabled for Flash Sector 4 (only if it's
allocated to Zone2)
1 : Execute-Only protection is disabled for Flash Sector 4 (only if it's
allocated to Zone2)
