X-BAR Registers
Table 7-31. XBARCLR2 Register Field Descriptions (continued)
Bit Field
4 INPUT5
3 INPUT4
2 INPUT3
1 INPUT2
0 INPUT1
916
Crossbar (X-BAR)
Type Reset Description
R=0/W=1 0h
Writing 1 to a bit in this register clears the corresponding bit in the
XBARILAT2 register.
Writing 0 has no effect
R=0/W=1 0h
Writing 1 to a bit in this register clears the corresponding bit in the
XBARILAT2 register.
Writing 0 has no effect
R=0/W=1 0h
Writing 1 to a bit in this register clears the corresponding bit in the
XBARILAT2 register.
Writing 0 has no effect
R=0/W=1 0h
Writing 1 to a bit in this register clears the corresponding bit in the
XBARILAT2 register.
Writing 0 has no effect
R=0/W=1 0h
Writing 1 to a bit in this register clears the corresponding bit in the
XBARILAT2 register.
Writing 0 has no effect
