2.14.1.4 CPUTIMER_REGS Registers

Table 2-81 lists the memory-mapped registers for the CPUTIMER_REGS. All register offset addresses not
listed in Table 2-81
modified.
Offset Acronym
0h TIM
2h PRD
4h TCR
6h TPR
7h TPRH
Complex bit access types are encoded to fit into small table cells.
used for access types in this section.
SPRUI33 – November 4 2015 – Revised January 2017
Submit Documentation Feedback
should be considered as reserved locations and the register contents should not be
Table 2-81. CPUTIMER_REGS Registers
Register Name
CPU-Timer, Counter Register
CPU-Timer, Period Register
CPU-Timer, Control Register
CPU-Timer, Prescale Register
CPU-Timer, Prescale Register High
Table 2-82. CPUTIMER_REGS Access Type Codes
Access Type Code
Read Type
R R
Write Type
W W
W1C W
1C
Reset or Default Value
-n
Copyright © 2015–2017, Texas Instruments Incorporated
Write Protection
Table 2-82
Description
Read
Write
Write
1 to clear
Value after reset or the default
value
Registers
Section
Go
Go
Go
Go
Go
shows the codes that are
