  • Page 1 Ergoline Vertical User Manual...

  • Page 2: Table Of Contents

    Ergoline Vertical User manual INDEX INTRODUCTION ........................3 IMPORTANT..........................3 WARRANTY..........................3 EQUIPMENT DATA ......................4 STANDARDS ..........................6 COMPULSORY PRECAUTIONS.................... 7 SAFETY RULES..........................8 MANUFACTURER’S RESPONSIBILITY..................8 INSTALLATION........................9 PACKAGING..........................9 CABIN ............................10 ELECTRICAL CONNECTION ...................... 10 HOW TO INSTALL THE UNIT ..................... 10 FUNCTIONING MODE .......................

  • Page 3: Introduction

    Ergoline Vertical User manual INTRODUCTION In thanking and congratulating on your choice, with this manual we are illustrating in the simplest possible way the general instructions for use and maintenance of the vertical solarium 48-180 high performance. IMPORTANT IMPORTANT: Before installing the equipment, carefully read the present manual and scrupulously follow the technical operating instructions and advice contained in it.

  • Page 4: Equipment Data

    Ergoline Vertical User manual EQUIPMENT DATA Model Ergoline Vertical Voltage supply 400 V ac Phase 3 + N + PE Frequency 50 Hz Amperage 20 A lamps 48x 180W 2mt Unit dimensions (1200 x 1000 x 2350) mm (door closed)
  • Page 5 Ergoline Vertical User manual 930mm B1 = 1270mm B4 = 440mm B6 = 600mm B8 = 1600mm 1230mm T1 = 1380mm T2 = 920mm Installation site In dry rooms with sufficient air supply (more than 2000 m ≤70 % Relative air humidity ≤30°C (86 °F)

  • Page 6: Standards

    Ergoline Vertical User manual Mains voltage 400 V / 3+N+PE / 50 Hz Cable cross section 5 x 4mmq Here is a copy of the label on the unit: Model: Serial number: UV type: Ergoline Vertical ****** Power supply: Year:...

  • Page 7: Compulsory Precautions

    Ergoline Vertical User manual COMPULSORY PRECAUTIONS Appliances that emit UVA and UVB rays can cause damage to the skin and eyes, due to the quantity and quality of the radiation and depending on individual sensitivity. Frequent exposure, in excessive doses and/or with poor or no protection, to the sun and a tanning lamp causes early ageing of the skin, and could result in sunburn and increase the risk of skin neoplasia.

  • Page 8: Safety Rules

    Ergoline Vertical User manual SAFETY RULES The owner or the employer must instruct the operational personnel on the accident risks, the devices arranged for the safety of the operator and the user (client), the risks of UV ray emissions and on the general accident prevention regulations provided for by international directives and by the law in the country where the appliance is used.

  • Page 9: Installation

    Ergoline Vertical User manual INSTALLATION PACKAGING The paking for the stand up unit is so composed: 1 pallette 2200 x 1100 x 930(high) mm 1 pallette 1200 x 1000 x 360(high) mm The external boxes are in Vulcan cardboard, this means a high robustness and a high resistance to hits.

  • Page 10: Cabin

    Ergoline Vertical User manual CABIN The aeration of the room (room/cubicle) must be adequate. The room will have a possible duct for the suction and extraction of the hot air produced by the tanning equipment. In any case, see the maximum working temperatures given on the dataplate of the appliance.
  • Page 11 Ergoline Vertical User manual Each panel of the unit is signed with a number from 1 to 6 (see on the right), so you can see which is the right position of the panel. Fix the brackets on the bottom side of panel 2 (brackets number 1 and 2) and panel 5 (brackets number 4 and 5), and insert the feet.
  • Page 12 Ergoline Vertical User manual Fix together panel 5 with panel 2 inserting panel 5 into long brackets as shown below, without fixing completely the screws. At the end of this operation the 2 panels can stand up by themselves. Fix on the bottom side of panel 4 the bracket numer 3 with the foot, as shown on the right.
  • Page 13 Ergoline Vertical User manual Panel 3 has no brackets on the bottom, this has to be inserted between panel 2 and 4, taking care to insert screws into holes. Then fix the nuts on the bottom. Seite 13 von 29...
  • Page 14 Ergoline Vertical User manual Put the roof on the 4 panels; take care about cables that have to pass through the right holes of the roof. Insert M6 nuts on rear side without fixing them at all. Insert plastic cylinders on the top side of panel 1 and 6 (doors);...
  • Page 15 Ergoline Vertical User manual Insert the door: First insert the bottom side (see picture on the right). Then lift up a little the front side of the roof and insert the top of the door (remember the cable trough the hole, see picture below).
  • Page 16 Ergoline Vertical User manual Connect white plastic connectors with the same number. Connect the power supply cable to the main filter, then push the cable through the channel on panel 4 as shown in following pictures; the cable comes out from the bottom side.
  • Page 17 Ergoline Vertical User manual Take the external handle and fix it on the left door using screws on bag 4 and aluminium cylinders on bag 5; take care on fixing step by step one all screw, otherwise you can damage the handle.
  • Page 18 Ergoline Vertical User manual Put the metal cover on the top. Connect the main cable to the power supply and switch on the unit, check that all lamps, fans and the main ventilator are on. Seite 18 von 29...

  • Page 19: Functioning Mode

    Ergoline Vertical User manual FUNCTIONING MODE PROGRAMMING The purpose of this chapter is to describe how the system works, giving a detailed description of several pages on the display and of several steps during a treatment; it’s also possible to setup some features of the unit.
  • Page 20 Ergoline Vertical User manual Pressing STOP button the session terminates, and if there’s a cooling time set up the following page will be shown: C O O L I N G S Y S T E M At the end the program will come back to page 1.
  • Page 21 Ergoline Vertical User manual C O O L I N G < > E N T E S C Press ESC for going back to page 1 Adjustment of the run-on time. The fan run on time can be adjusted between 30 seconds and 5 minutes by the european version and between 3 minutes and 5 minutes by the US-Version.
  • Page 22 Ergoline Vertical User manual If a start arrives from the external connector, the session begins: 9e L E F T T I M E 0 0 : 1 3 Increasing time is displayed S T O P 10 V E R S I O N : E N G 0 4 <...

  • Page 23: Remote Control Connection

    Ergoline Vertical User manual REMOTE CONTROL CONNECTION On the external side you have a 6-wire cable, that’s outcoming from the back bottom of the unit, to allow the interfacing to the external control. In the drawing below you can see how to connect the unit to a generic external control.

  • Page 24: Maintenance Register

    Ergoline Vertical User manual MAINTENANCE REGISTER Model of equipment: Serial No.: Intervention No: Date of intervention: Total hours of operation: Type of intervention: Lamp replacement Starter replacement Other______________________________________________________________________________ Next intervention in________________ hours Notes ____________________________________________ Stamp and signature of authorized ____________________________________________...
  • Page 25 Ergoline Vertical User manual Model of equipment: Serial No.: Intervention No: Date of intervention: Total hours of operation: Type of intervention: Lamp replacement Starter replacement Other______________________________________________________________________________ Next intervention in________________ hours Notes ____________________________________________ Stamp and signature of authorized ____________________________________________ technician ____________________________________________ Model of equipment: Serial No.:...
  • Page 26 Ergoline Vertical User manual Model of equipment: Serial No.: Intervention No: Date of intervention: Total hours of operation: Type of intervention: Lamp replacement Starter replacement Other______________________________________________________________________________ Next intervention in________________ hours Notes ____________________________________________ Stamp and signature of authorized ____________________________________________ technician ____________________________________________ Model of equipment: Serial No.:...
  • Page 27 Ergoline Vertical User manual Model of equipment: Serial No.: Intervention No: Date of intervention: Total hours of operation: Type of intervention: Lamp replacement Starter replacement Other______________________________________________________________________________ Next intervention in________________ hours Notes ____________________________________________ Stamp and signature of authorized ____________________________________________ technician ____________________________________________ Model of equipment: Serial No.:...

  • Page 28: Notes

    Ergoline Vertical User manual NOTES TANNING ADVICE CARD CAUTION INTENSE LIGHT: DO NOT STARE AT THE EMITTER Ultraviolet radiation or UV appliances can damage the skin and eyes. These biological effects not only depend on the quantity and quality of the radiation but also on the individual sensitivity of the skin and eyes.

  • Page 29: Exposure Times Card

    Rapporto di prova misure radiometriche su apparecchiatura abbronzante Misurazione eseguita con modalità di prova come indicato nella normativa EN60335-2-27 Modello: Ergoline Vertical Costruttore: Quadra Medical srl Tipo lampada: Lighttech Engineering Sample 180R Longlife No5/226, c252 Tipo alimentatore: ERC HID/90 180W 1,5A 230V 50Hz , cod. MPEE001019...
  • Page 30 2. Grafico: Curva irradianza spettrale 16,00 14,00 12,00 10,00 8,00 6,00 4,00 2,00 0,00 Lunghezza d'onda [nm] 3. Tabella tempi di esposizione: Fototipo II Fototipo III Fototipo IV 1. Sessione 3 min 3 min 3 min 2. Sessione 3 min 3 min 4 min 3.
