- Page 1 Aerotech Baffl e Actuator Instruction Manual BA1701 Series Baffl e Actuator Models: BA1701 • BA1701-30 © Munters Corporation, July 2017 QM1154r5...
-
Page 2: Step
With the proper installation and maintenance it will provide many years of service. Please Note: To achieve maximum performance and insure long life from your Munters product it is essential that it be installed and maintained properly. Please read all instructions carefully before beginning installation. Warranty: For Warranty claims information see the “Warranty Claims and Return Policy”... -
Page 3: Table Of Contents
Page 1. Unpacking the Equipment Parts List Dimensions 2. Installation Instructions 3. External Cabling Methods 9-10 4. Electrical Wiring 5. Operation 12-13 6. Maintenance 7. Troubleshooting 15-17 8. Exploded View and Parts List 18-19 © Munters Corporation, July 2017 QM1154r5... -
Page 4: Unpacking The Equipment
Frequency: 60 Hz Load Capacity: 700 lbs. 1.2 Inlet Dimensions Note: These actuators are designed to open or close Aero-Baffle accordingly from signals received from any one of Munters Air-Monitor Controls or Environmental Computer Controls. © Munters Corporation , July 2017 QM1154r5... -
Page 5: Installation Instructions
Secure to framing using (4) Lag Screws [A]. See Figure 2A for typical installation of a ceiling mounted actuator. See Figure 2B for typical installation of a wall mounted actuator. High Voltage, disconnect power before servicing. Figure 1B Figure 1A © Munters Corporation, July 2017 QM1154r5... - Page 6 Chapter 2 Installation Instructions Figure 2A SIDE VIEW CEILING MOUNT 23 ⁄ ” LOOKING UP FROM FLOOR Figure 2B WALL MOUNT SIDE VIEW FRONT VIEW © Munters Corporation , July 2017 QM1154r5...
- Page 7 Pull 2 threaded ends through and attach to the Ball Nut Flange using (4) Nuts [C]. See Figures 3. Figure 3 Step 3 Secure Open Eye Lag Screw [G] to wall in direct line with BA1701. Then attach Pulley [F] to Eye Screw as shown. See Figures 4. Figure 4 ©...
-
Page 8: Installation Instructions
Cable Clamp [B]. See Figures 5. Figure 5 Step 5 Place Cable Thimble [E] over hook end of Turnbuckles [H]. Place Cable Assembly [D] in groove of Thimble [E]. See Figures 6. Figure 6 © Munters Corporation , July 2017 QM1154r5... -
Page 9: External Cabling Methods
For every 1” the baffle machine travels the inlets will move 1”. The normal load will be applied to the baffle machine. © Munters Corporation, July 2017 QM1154r5... -
Page 10: External Cabling Methods
This is because for every 1” the baffle machine travels the inlets will move ½”. Only half of the load will be applied to the baffle machine, therefore, it will have twice the pulling capacity. © Munters Corporation , July 2017 QM1154r5... -
Page 11: Electrical Wiring
Step 2 Each actuator should have independent overload protection matched to its motor. High Voltage, disconnect (Munters Circuit Breaker Catalog No. SY2010 power before servicing. Step 3 Open, Close and Neutral outputs from the air monitor control are to be wired to Open, Close and Neutral inputs in actuator. -
Page 12: Operation
Slide Close Limit Switch against Guide Block so that it activates Close Limit Switch and tighten screws. See Figure 9. Manually run Baffle Machine open about 1” and back close to check for proper full close position. Figure 9 © Munters Corporation , July 2017 QM1154r5... -
Page 13: Operation
Machine close about 1” and back open to check for proper full open position. Figure 10 Figure 11 Step 3 Place all switches and controls in AUTO. Test operation of Baffle Machine using Air-Monitor Control or Environmental computer control © Munters Corporation, July 2017 QM1154r5... -
Page 14: Maintenance
Step 1 - Apply power to the actuator in the open and then the close direction. Step 2 - Verify that the gearmotor will operate in both directions. Step 3 - If the unit will not operate, refer to the Troubleshooting procedures for further instructions. © Munters Corporation , July 2017 QM1154r5... -
Page 15: Troubleshooting
4. Check output of Actuator control to make sure the actuator is receiving a signal to open. If voltage is not present, check main electrical service panel in building and wiring from control. *Note: For BA1701-30 gray and blue motor leads are reversed. © Munters Corporation, July 2017 QM1154r5... - Page 16 Chapter 7 Troubleshooting Figure 12 BA1701 © Munters Corporation , July 2017 QM1154r5...
-
Page 17: Troubleshooting
Chapter 7 Troubleshooting Figure 13 BA1701-30 © Munters Corporation, July 2017 QM1154r5... - Page 18 Exploded View © Munters Corporation , July 2017 QM1154r5...
- Page 19 Description Qty. Item AC1330 Lower Frame Section with Base, CTD-GZ AC1329 Upper Frame Section, CTD-GZ AC1333 Cover Only for BA1701, AL AC1325C Motor (4RJ20), 120V, with Capacitor AC1443 Gearhead, 360:1, S8DA360B1A-A757 (Replaces 4GB360KA) AC1446 Gearhead, 60:1, S8DA60B1A-A765 (Replaces 4GB60KA) FP2053 Prop Fastener, ⁵⁄₁₆”...
- Page 20 BA1701 Baffl e Actuators are developed and produced by Munters Corporation, Lansing, Michigan U.S.A. 1-800-227-2376 Munters Europe AB, Isafjordsgatan 1, P.O. Box 1150, SE-164 26 Kista, Sweden. Phone +46 08 626 63 00, Fax +46 8 754 56 66. Munters Corporation 2691 Ena Drive Lansing, MI 48917 U.S.A. Phone +1 800-227-2376, Fax +1 517-676-7078 www.munters.us...
