Page 1: User Manual
SWIT Electronics Co., Ltd. Model: S-1071H+ 7” 3GSDI & HDMI LCD Monitor User Manual Ver：A Please read this User Manual throughout before using. -
Page 2: Preface
2. All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners. 3. Due to constant effort of product development, SWIT reserves the right to make changes and improvements to the product described in this manual without prior notice. -
Page 3: Maintenance
Maintenance Warning 1. In order to reduce the risk of fire and electrical shock, do not lay this product in rain or damp places. 2. Please keep away from the strong magnetic field; it may cause the noise of the video and audio signals. -
Page 4: Table Of Contents
Contents Preface ..............................2 Maintenance ............................3 Contents ..............................4 Packing list ............................... 4 Introduction .............................. 4 Installation Dimensions ..........................5 Operation Instructions ..........................6 Front Panel ............................6 OSD ..............................7 Back Panel ............................9 Main Menu ............................. 10 Battery Plate ............................ -
Page 5: Installation Dimensions
Installation Dimension The main body (in mm) -
Page 6: Operation Instructions
Operation Instructions ·Front Panel ⑴ PHONE: 3.5mm earphone socket, for SDI/HDMI embedded audio and analog audio monitoring. ⑵ POWER: Power on/off ⑶ Button SDI: Press to switch the input signal to SDI HDMI: Press to switch the input signal to HDMI CVBS: Press to switch the input signal to Composite video F1～F5: User definable function keys. -
Page 7: Osd
·OSD ⑴. Time code（SDI） Under SDI input, it can display Time code. If no Time code information is detected, it will be displayed as “TC: UNLOCKED”. ⑵. UMD Set up the UMD under ‘UMD” submenu. ⑶. AFD (SDI) User can set function keys F1～F5 or GPI pins as “AFD” to turn on or off this function. If no relevant information is detected, it will be displayed as “AFD: UNLOCKED”. -
Page 8: Audio Alarm
Introduction of audio and video functions 2-ch embedded audio meters Under SDI/ HDMI/ CVBS, it displays 2 channels embedded audio meters. The audio meter is green, and will turn yellow when audio exceeds -20dB, and turn red when audio exceeds -9dB. ... -
Page 9: Back Panel
⑵ DC 12V IN: Connect with the provided DC12V 4-pin XLR power adapter, and support 6.5-17V wide voltage Input (Pin 1: Negative, Pin 4: Positive) ⑶ Battery mount connector Connect with SWIT S-7004 series quick release battery plate, and then mount corresponding V-mount or DV batteries. See details in “Optional Battery Plate”. ⑷ Video Signal Interface... -
Page 10: Main Menu
Main Menu S-1071H+ has OSD to adjust the parameters and settings, for example: Picture, color temp., function keys, etc. 1. Press “OK” button, the main menu will popup from the left top of the screen. The selected main menu highlights in yellow. 2. - Page 11 Submenu introduction（the default values are marked with underline ） 1. Exit & Status Displays the current status, the details are as down below: *1 Display the current video signal and format *2 Display the current function keys setup 2. Picture To adjust picture parameters 3.
- Page 12 *1 Function keys F1-F5 can be setted as the down below functions: Aspect Ratio, Scan Mode, Zoom Mode, Mute, Freeze Frame, Flip Mode, color temp., Time code, Zebra, Audio Bar, False Color, AFD, H/V Delay, R/G/B/Mono, Marker, Color Bar, UMD, Audio Alarm, Max Backlight, Focus Assist For example: Set F3 to “R/G/B/Mono”...
- Page 13 7. Marker *1 When “Fit Marker” is “Off”, the size of safety area is benchmarked against the actual display screen, accounting for 80% ~ 95% of actual display screen. When “Fit Marker” is “On”, the size of safety area is benchmarked against the area inside the scales marker, accounting for 80% ~ 95% of the area inside the scales marker.
- Page 14 When set to “Off”, source scan will not be supported. *2 Logo When powered on, the screen will display SWIT logo. *3、*4 Update Driver/ Kernel ⑴ Power the monitor, insert the USB equipment with update software into the USB socket.
- Page 15 User can set “Key Inhibit” under “key Inhibit” submenu to “Off” to recover the functions of all buttons. Optional Battery Plate 1. Battery Mount choice S-1071H+ monitor can use V-mount, Gold mount and various DV batteries by connecting with SWIT S-7004 series battery plates. There’re following types of S-7004 for choice: Model Compatible battery type...
-
Page 16: Battery Plate
2. Installation of S-7004F/D/J/C/U/E/B/V/I snap-on type DV battery plate: S-7004F/D/J/C/U/E/B/V/I DV plate is snap-on type, quick release and interchangeable. Please follow the instructions to install: (1) Please make sure the power terminals are clean and in well condition before use. (2) Align the S-7004 DV plates slots to the bolts of the monitor rear panel, and press tightly in. -
Page 17: Specification
Specification LCD Performance Size 7 inch Display area 153.6×90 mm Resolution 1024×RGB×600 Color 8 bit Aspect ratio 16:9∕4:3 Brightness 400 cd∕㎡ Contrast 900:1 Viewing Angle Horizontal: 160°∕Vertical: 160° Input/output BNC×1 3G/HD/SD-SDI input×1 BNC×1 CVBS input Input HDMI×1 HDMI input RCA×2 Analog audio input USB×1 BNC×1... -
Page 18: Trouble-Shooting
Trouble-shooting Symptom Possible Causes Solution Please check if the power is connected, and then The power is not turned on press ”POWER” button to turn on the monitor Unstable power voltage Reconnect to power supply BNC or HDMI cable loose No display Check and correctly connect the contact or not correctly...
