Page 1: User Manual
SWIT Electronics Co., Ltd. Model: S-1243F 23.8" Broadcast Studio LCD Monitor User Manual Ver: V1.0.0V01 Please read this User Manual throughout before using. -
Page 2: Preface
2. All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners. 3. Due to constant effort of product development, SWIT reserves the right to make changes and improvements to the product described in this manual without prior notice. -
Page 3: The Monitor
Maintenance Warning 1. In order to reduce the risk of fire and electrical shock, do not lay this product in rain or damp places. 2. Please keep away from the strong magnetic field; it may cause the noise of the video and audio signals. -
Page 4: Table Of Contents
3. Power adaptor + power cable Introduction S-1243F adopts IPS LCD panel, with resolution 1920×1080 and wide viewing angle H178°⁄V178°. It supports 2 x 3GSDI(Level A/B), 1 x HDMI, 1 x CVBS, 1 x Y/Pb/Pr, 1 x VGA and 1 x analog audio input. -
Page 5: Installation Dimensions
Installation Dimension The main body (in mm) With desktop stand feet (in mm) For optional purchase Item Name Item Model V-mount battery plate S-7004S Gold-mount battery plate S-7004A B attery plate 、 、 、 、 Installation 1. Take off the rub cover on the rear panel; see Fig (1). 2. -
Page 6: Operation Instructions
Operation Instructions Front Panel (1) Desktop Stand Feet (2) Speaker: For SDI/HDMI embedded audio and analog audio monitoring. (Will not work if earphone is plugged in) (3) Illuminated Push Button SDI1: Press “SDI1” to switch to SDI input 1 SDI2: Press “SDI2” to switch to SDI input 2 HDMI: Press “HDMI”... -
Page 7: Osd
Time code S DI ⑴ （ ） Under SDI input, it can display Time code. If no Time code information is detected, it will be displayed as “TC UNLOCKED” User can set function keys F1 F 4 or GPI pins as “Time code” to turn on or off this function. ～... - Page 8 “UNLOCKED” in the audio bar. Time code （ （ （ （ S DI ） ） ） ） Under SDI input, it can display the SMPTE time code (VITC1, VITC2 or LTC) on the top of the screen, which is used extensively for synchronization, and for logging and identifying material in recorded media.
-
Page 9: Rear Panel
Rear Panel ⑴ Handle DC IN 11V-17V BACK UP: Back up power input, connect with DC11V 1 7V 4-pin XLR power ⑵ ～ adapter. (Pin 1: Negative, Pin 4: Positive) ⑶ DC IN 11V-17V MAIN: Main power input, connect with DC11V ～... -
Page 10: Main Menu
Main Menu S-1243F has OSD to adjust the parameters and settings, for example: Picture, color temp., function keys, etc. 1. Press “MENU/ENTER” button, the main menu will popup from the left top of the screen. The selected main menu highlights in yellow. - Page 11 Exit & Status Displays the current status, the details are as down below: *1 Display the current video signal and format *2 Display the current function keys setup 2. Picture To adjust picture parameters 3. Color Temp To select different color temperature or setup user-defined color parameters. * Only “Color Temp”...
- Page 12 Alarm, Focus Assist , Aspect Ratio, Scan Mode, Zoom Mode, Mute, Freeze Frame, CVBS, HDMI , SDI1, SDI2 ,Color Temp, Time Code, Zebra, Vector. For example: Set F3 to “R/G/B/Mono” under “Function key” submenu. User can press F3 on the front panel to adjust the parameters of “R/G/B/Mono”, and the “R/G/B/Mono”...
- Page 13 Max 8 letters are supported. Select “Exit” to quit and save settings, the source ID will be displayed on top or bottom of the screen. UMD setup: Connect the external control equipment with S-1243F ⑴ ⑵ Set “Display Type” to “UMD” under UMD submenu ⑶...
- Page 14 Aspect ratio: 4:3 Aspect ratio: 4:3 Safety Area: 85% Safety Area: 85% Center Marker: On Center Marker: Off Fit Marker: Off Fit Marker: On 8. Audio *1 When “Bar Frame” is set to “Off”, only the audio meter will be displayed When “Bar Frame”...
- Page 15 in red. Channel 1-2 Channel 1-8 Channel 1-16 9. Vector 10. Waveform *1: Only the “WFM Single Line” is set to “ON”, the “WFM Line Count” can be adjusted. “WFM Single Line” is to display the selected line waveform of “WFM Line Count” WFM Single Line O ff WFM Single Line...
- Page 16 CVBS. When set to “No”, update model will not be supported. *2 Logo When powered on, the screen will display SWIT logo. *3 Green Mode When no recognizable signal is detected and opreation time reaches the time selected in “Idle Duration”, then the monitor will turn to green energy saving mode that is “Green mode”.
-
Page 17: Specification
on rear panel of the monitor; ② Press “MENU/ENTER”, enter “Main Menu” - “System”, and select “Update Driver” or “Update Kernel”; Set “Yes”, the monitor will upgrade automatically; ③ ④ During firmware upgrade, the screen will display progress percentage. Pless do not cur off power during the upgrade;... -
Page 18: Trouble-Shooting
