Si-86.book Page 22 Friday, June 23, 2000 10:26 AM
General Functionality
Room temp. < 18˚C
Room temp. ≥ 18˚C
3. Required fan speed
Thermostat ON
Thermostat OFF
Thermostat ON and dry on powerful
operation
∗ For both H / J type
Night set mode
The night set mode is activated when the off timer is set. It restricts the operation frequency, to minimize
the noise.
cooling
heating
∗ For both H / J type
22
The frequency command for every zone is stated below.
(Please note that an operation will not carry out in the commanded frequency sometimes in case a
protection control like a freeze-protection etc. will be actuated.)
Room temperature Room temp. zone
A
except A
A
B
D
E
F
Fan speed changes the rotation speed every time when a thermostat switches over ON and OFF.
When the thermostat becomes Off, fan continues to operate 10 minutes more with low speed so as to
prevent recovery of humidity caused by reevaporation of the drain water, and then stops.
Item Description
The set temperature
stays on for one hour,
then decreases slightly
for economical
operation.
Timer operation
Night set circuit on
A
B
The set temperature
stays on for one hour,
then increases slightly
for economical
operation.
Command frequency
H type (25 / 35) J type (25 / 35)
0 / 0Hz
36 / 36Hz
0 / 0Hz
36 / 36Hz
36 / 36Hz
40 / 40Hz
40 / 44Hz
Fan rpm (thermostat ON)
H type (25 / 35) J type (25 / 35)
800 / 800rpm 970 / 980rpm
700 / 700rpm 800 / 800rpm
850 / 910rpm 1050 / 1050rpm
Drawing
A
0,5˚C
B
0,5˚C
1 hour 30 min.
0,5˚C
A
+0.5˚C temperature shift
temperature shift
B Temperature setting remains
When the outside temperature is lower than 27˚C and the room
temperature is at the set temperature.
When the outside temperature is 27˚C or higher.
Thermostat
setting
Timer operation 1 hour later
Night set circuit on
SIE-86
0 / 0Hz
34 / 34Hz
0 / 0Hz
34 / 34Hz
40 / 40Hz
42 / 42Hz
42 / 42Hz
temperature setting +1˚C
temperature setting +0.5˚C
temperature setting
operation stops
at the set hours
(RL017)
2˚C
(RL018)
Main Function
