Instruction
Intelligent Eye
"Intelligent Eye" is the infrared sensor which detecs the
human movement.
SENSOR
1
Press
is operating. (The Sensor lamp lights up.)
n
To cancel the "Intelligent Eye",
SENSOR
press . (The Sensor lamp goes off.)
[EX.]
When somebody in the room
• Normal operation
When nobody in the room
• 20 min. after, start save operation.*
Sombody back in the room
• Back to normal operation.
"Intelligent Eye" is useful for
Ener gy Saving
* Save operation
l
Change the temperature –2˚C in heat/ +2˚C in cool/ +1˚C in
dry mode from set temperature.
l
Decrease the air flow rate slightly in fan operation.
Notes on "Intelligent Eye"
l
Application range is as follows.
Vertical angle 40˚
(Side View)
80˚
l
Sensor may not respond when you are 5m or
more away. (Check the application range)
l
Sensor detection sensitivity changes according
to indoor unit location, the speed of passersby,
temperature range, etc.
l
The sensor also mistakenly detects pets,
sunlight, fluttering curtains and light reflected
off of mirrors as passersby.
46
While the air conditioner
(The sensor lamp lights up.)
(The sensor lamp goes off.)
(The sensor lamp lights up again.)
Horizontal angle 50˚
(Top View)
50˚ 50˚
n
Adjusting the angle of the
Intelligent-eye sensor
•You can adjust the angle of the Intelligent-eye
sensor to remove the detection area.
(Adjustable angle: 15˚ to right and left of
centre)
15˚
•Gently push and slide the sensor to adjust
the angle.
Moving the sensor to the left Moving the sensor to the right
•After adjusting the angle, gently wipe the
sensor with a clean cloth, being careful not to
scratch the sensor.
CAUTION
• Do not hit or violently push the Intelligent-eye sensor. This
can lead to damage and malfunction.
l
Saving operation will not go on during
powerful operation.
l
Night set mode (see page 44.) will not go on
during you use Intelligent Eye.
l
You can sleep more comfortablly by using
"Good Sleep Cooling Operation (G-SLEEP)"
function (see page 45.) at the same time.
CAUTION
Do not place large objects near the sensor.
Also keep heating units or humidifiers outside
the sensor's detection area.
This sensor can detect objects it shouldn't as
well as not detect objects it should.
SIE-86
Intelligent-eye
15˚
sensor
13
(RE014)
