Install The Exterior Keypad; Install The Interior Assembly; Install The Batteries And Perform The Door Handing Process - Kwikset Smartcode 914 Installation And User Manual

3

Install the exterior keypad

A
What is the diameter of the hole in the door?
Diameter is 2 1/8"
(54 mm)
or
2 1/8"
54 mm
"D" is required for installation. "D" is not needed for
Install "D" on "F". installation. Discard "D".
F
D
B
Locate screws for step 3C and keep them within reach.
T
4

Install the interior assembly

A
Remove battery cover and battery pack from interior assembly.
a
Make sure turnpiece is in
the vertical position.
c
Make sure
turnpiece shaft is
rotated as shown.
L
5

Install the batteries and perform the door handing process

This step will teach your lock the orientation of your door and is crucial to lock operation.
A
Install 4 AA batteries in battery pack.
K
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
C
Install exterior keypad and mounting plate.
Diameter is 1 1/2" a
(38 mm)
1 1/2"
38 mm
D
c
screws evenly.
B
b
L
M
d
K
Do not install
batteries
until step 5.
L
B
Press and HOLD the Lock button
while installing battery pack.
Hold button until the latch bolt
starts moving on its own.
2 / 4
actual
size
b
F
Cable goes
underneath latch.
d
Keep parallel to
edge of door.
T
T (2x)
Tighten
Install interior assembly onto mounting plate.
a
b
L
align
Lay excess cable lat inside the
Ensure tight cable
bottom of the interior housing.
connection.
c
d
C
Did the latch bolt retract and extend on its own
when the battery pack was installed?
YES
Door handing process
was successful! Proceed
to next step after latch
bolt stops moving.
T
Support exterior
assembly during
mounting plate
installation.
G
Route cable through
center hole, then push
cable into bottom hole.
E
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (T).
Remove key when
inished and make
sure the latch bolt
is fully extended.
actual
size
U
U
(2x)
bottom
hole
Note: Latch
bolt will only
retract half way.
NO
or
Remove battery pack,
wait 15 seconds, then
attempt the process again.
