SmartCode at a Glance

Exterior
Lock
button
Keypad
Keyway
SmartKey
tool hole

Switches and Status LED colors

Switches
On O
1 2 3 4
Switch Function
Door lock status LED blinks every 6
1
seconds
Lock automatically re-locks door 30
2 seconds after unlocking. Disabled if no
codes are programmed.
3 Audio
4 Not used.

Deleting a single user code

Note: All codes may be deleted at once if the mastercode is enabled. For more information about the
mastercode, consult the Programming and Troubleshooting Guide.
1 Keep door open. 2 Press Lock 3 Enter user code
Press Program button once.
button once.
5 Re-enter user code. 6 Press Lock
If unsuccessful
button once.
Make sure to enter
the same valid code
in steps 3 and 5.
If no button is pressed for ive seconds, the system will time out, and
you will need to restart the procedure.
Network Information
Removing the lock from the network
Follow your smart home system's instructions
to remove the lock from the network. When
prompted by the system, press button A" on the
lock interior once.
Z Wave System Notes
This product is a security enabled Z-wave Plus product and must be used with a Security
Enabled Z Wave controller to be fully utilized. Z Wave is a "Wireless mesh network," and
results may vary based on building construction and communication path.
To assure interoperability, each Z Wave product must pass a stringent conformance test to
assure that it meets the Z Wave standard for complete compliance with all other devices and
controls. The Z Wave identity mark assures consumers, integrators, dealers and manufacturers
that their products will reliably perform with any other Z Wave device. And, regardless of the
vendor, always powered nodes may act as a repeater for Kwikset/Weiser/Baldwin products.
Z Wave Con iguration and Association Parameters are available
on the SmartCode 914 page at www.kwikset.com.
Reference Guide
Interior (cover removed)
Back
panel
Button "A" Button "B"
Program
button
Switches
Status
LED
Turnpiece
shaft
Note: When the cover is removed,
the turnpiece shaft can be used to
manually lock and unlock the door.
Status
LED
Color Lock Status
Blinking green Unlocked
Blinking amber Locked
Blinking red Low battery
Door handing process
did not work properly.
Solid red See the online
Programing and
Troubleshooting Guide.
4 Press Lock
to be deleted. button once.
Test code
While the door is
open, test the user
code to make sure
it no longer unlocks
the door.
4 / 4

System Alerts

Alert Reason
Keypad lashes red once with
One incorrect code entered.
one beep*.
No user code programmed.
Keypad lashes red three Programming timeout after ive
times with three beeps*. seconds.
Unsuccessful programming.
Keypad lashes red 15 times Three incorrect codes entered
with 15 beeps* within one minute.
Keypad lashes red with fast
beeping sound for three to Low battery.
four seconds.
Keypad lashes green with
Door jammed while attempting
continuous beeping sound
to lock.
for two seconds.
Interior assembly is
Lock beeps continuously.
disconnected from exterior.
*Beeping sound will only be heard if switch #3 is on.

Troubleshooting

A complete Programming and Troubleshooting Guide is
available on the SmartCode 914 page at www.kwikset.com.
Factory Reset
A factory reset will delete all codes associated with the lock,
and it will remove it from your smart home system.
1 Remove 2 Press and HOLD the Program
battery pack. button while reinserting
the battery pack.
Keep holding the button for 30
seconds until the lock beeps
and the status LED lashes red.
3 Press the Program button 4 Perform the door handing process again
once more. When the LED
lashes green and you
hear one beep, the lock
has been reset.
Important Safeguards
1. Read all instructions in their entirety.
2. Familiarize yourself with all warning and caution statements.
3. Remind all family members of safety precautions.
4. Protect your user codes and mastercode.
5. Dispose of used batteries according to local laws and regulations.
CAUTION: Prevent unauthorized entry. Since anyone with access to the back panel
can change the user codes, you must restrict access to the back panel and routinely
check the user codes to ensure they have not been altered without your knowledge.
The use of a mastercode can help protect your system's settings.
WARNING: This Manufacturer advises that no lock can provide complete security
by itself. This lock may be defeated by forcible or technical means, or evaded by
entry elsewhere on the property. No lock can substitute for caution, awareness of
your environment, and common sense. Builder's hardware is available in multiple
performance grades to suit the application. In order to enhance security and reduce
risk, you should consult a quali ied locksmith or other security professional.
Solution
Re-enter code.
Program at least one user code.
Attempt programming procedure again.
Re-enter code after 60 second keypad
lockout.
Replace batteries.
Manually re-lock door. If needed,
reposition strike.
Remove battery pack, reconnect the interior
to the exterior, then reinstall battery pack.
Status
LED
to teach the lock the orientation of the
door, pair the lock with your smart home
system, and add user codes to your lock.
