Kwikset SmartCode 909 Installation Manual

60730 / 01
Installation Guide
Required Tools
Use and programming
instructions are located on the
Additional Tools (depending on application)
reverse side of this document.
3
Adjust the backset of latch (if needed)
A B
Hold the latch in front of the If the latch holes are
door hole, with the latch face centered in the door hole, no
ush against the door edge. adjustment is required.
Proceed to step 4.
If the latch holes are NOT
centered, adjust latch. See
"Latch Adjustment."
A / A2
Latch Adjustment (only if needed)
180°
7
Disassemble interior assembly and load battery pack
A B C
L
M
Make sure
turnpiece is
N in the vertical
position.
D AA x4
L
Do not install
Ensure correct polarity. For best results,
battery pack yet!
use new non-rechargeable Alkaline
batteries only.
10
Install strike
B
D (2x)
Parts in the Box
Latch and Strike Exterior Assembly Interior Assembly
C
A B
D
E
K
F
A2
G
If needed, please contact
P Q
Kwikset to order a drive-in
latch for your lock.
J H
R S
Kwikset
1-800-327-5625
www.kwikset.com
4
Install latch
For doors with chiseled edge For doors without chiseled edge
A
A2
B
A C (2x)
C D
wood
block
8
Install interior assembly
A B
N
K
Ensure tight cable connection.
11
Program the lock
Programming
instructions are
located on the
reverse side of
this document.
1
Check dimensions
L 2-3/8" (60 mm)
or
2-3/4" (70 mm) 1-3/8" — 1-3/4"*
35 mm — 44 mm*
M
1-1/2" 2-1/8"
N or
38 mm 54 mm
Additional door preparation may be
required for doors with 1-1/2" (38 mm)
holes. Consult the drilling instructions at
www.kwikset.com/doorprep.
5
Prepare exterior keypad
For doors with 2-1/8" (54 mm) holes
2-1/8"
54 mm
E
For doors with 1-1/2" (38 mm) holes
F
1-1/2"
38 mm
C D
Lay cable
at against
the interior
housing.
12
Install the battery cover and re-key the lock
A B
S
M
ball
tip R (3x)
Keep "S" in a safe place, as you will
need it to access the back panel for
additional programming.
2
Extend latch bolt
1"
25 mm
*Service kits for 2-1/4"
(57 mm) thick doors are
available through Kwikset.
6
Install keypad and mounting plate
A B
Cable goes
underneath latch
G
C
Keep parallel to
edge of door
G
Tighten
screws
evenly
Q (2x)
9
Perform door handing process
This step will teach your lock the orientation of your door
and is crucial to lock operation.
A Press and hold the
Lock button while L
installing battery
pack (L).
P (2x)
Hold button until the
latch bolt starts
moving on its own.
HOLD
latch bolt
Template
C
If your door requires drilling, cut out the template and place it on the exterior side of the door.
Complete door drilling instructions are available on the SmartCode deadbolt page of www.kwikset.com.
Edge Face
J
Fold
If needed, re-key the lock to
work with your existing key.
See the supplied SmartKey
Centerline
Re-key instructions for more
information.
2-3/8" (60 mm)
2-3/4" (70 mm)
Backset
A / A2
Route cable
through center hole,
then push cable
into side hole.
K
center hole
side hole
D
Insert key and test latch.
H
If latch does not extend or
retract smoothly, adjust
screws (Q).
Remove key when nished
Q
and make sure the latch
bolt is fully extended.
B
Did the latch bolt retract
and extend on its own
when the battery pack
was installed?
YES NO
Door handing process Remove battery pack,
was successful! Proceed wait 15 seconds, then
to Step 10 after latch bolt attempt the process
stops moving. again.
