1 Introduction

1.1 Overview

The UltraSAM4W is an Industrial 3G/4G Ethernet Router designed to perform data communication functions between
a wired Local Area Network (LAN) and the cellular network (Wide Area Network, WAN).
Its environmental qualities, notably its wide temperature range of operation, its robustness and throughput
performances, make it a perfect tool for industrial application like metering, telemetry or security monitoring.

1.2 Features


HSPA+/UMTS/4G/LTE Wireless Module

10/100Mbps Ethernet Port

External Antenna (Main Antenna and Aux Antenna)

GPS Feature (Optional Antenna)

12VDC 1.5A Input Power Supply (Microfit Connector)

Protocols and protocol settings: TCP/IP, DHCP server, DDNS, NAT, non-NAT, port forwarding, HTTP, ARP, PPP,
APN, NTP, VPN – IPsec, VPN – PPTP, VPN – OpenVPN

Web Base Interface, Periodic Administration, Local/Remote Firmware Upgrade via HTTP, SIM Management, Time
Configuration, NTP Time Synchronization.

SMS Administration and control

1.3 Packing List/Accessories

The UltraSAM4W modem is delivered with:

External Multiband Antennas with SMA RF Connector

RJ45 Ethernet Cable for PC Connection

Quick User Guide

220Vac Adapter with Microfit Connector

1.4 Optional Accessory


External GPS antennas with SMA RF connector
