Ultra SAM4W User Guide V1.3

5.9.2 Ipsec

The UltraSAM4W modem can help you set up a VPN (Virtual Private Network) over a public telecommunication
infrastructure such as the Internet, providing remote offices or individual users secure access to your organization's
network. It aims to avoid an expensive system of owned or leased lines that can be used by only one organization.
To create a new profile, please click Add button.
Enable VPN
Profile Name
Remote Gateway
Road Warrior
Local LAN
33
Enable / Disable Ipsec service
User defined Ipsec profile name
Remote Ipsec Gateway
-
Public IP address of the Ipsec server
Remote Address/Net to Join
-
IP address of Remote server on the VPN connection (eg. 192.168.1.1)
Remote Address/Net Mask
-
Network Mask of Remote server on the remote network
Click this to configure the VPN connection for Road Warrior (connection from a
dynamic IP Address) use.
Local Address/Net to Join
-
Local IP address of the VPN connection
