Ultra SAM4W User Guide V1.3
1. Access UltraSAM4W Main Page, Enter APN/PIN and achieved Public IP condition.
2. Internet Setting -> VPN -> OpenVPN
3. Click Add button to create a new profile
4. VPN Edit
Profile Type
Enable VPN
Profile Name
OpenVPN Type
Server Port
VPN Network Address
VPN Network Mask
Click Generate DH
If first time using, Generate DH will take over 30mins to complete
5. After finishing step 3, fill in Server Certificates' information & click Generate CA certificate
6. Authentication Type, choose Certificate
7. Certificate Management, adding certificate name and fill in the corresponding information
8. Finished Step 6, click Generate, this action should waiting around 3~5 seconds, and click Download to download
the certificate to PC terminal
9. Repeat Step 6~7 for multi-certificate generation
10. Click Save
TEMPLATE:
UltraSAM4W Client
1. Access UltraSAM4W Main Page, Enter APN/PIN and achieved Public IP condition.
2. Internet Setting -> VPN，Select OpenVPN with type Client
Server IP Address
Server Port
3. Click Upload to upload the Certificate generate by the server
37
OpenVPN
Enable
Any profile name is fine
Server
1194 (any port which is not being used) UDP/TCP
10.0.0.0（Private Network）
255.255.255.0
Fill in the Server Public IP Address
Server's Port number & connection type UDP/TCP
