Ultra SAM4W User Guide V1.3
3.2 Antenna, Ethernet & Power Plug Connection
Before connecting the Power Supply to your UltraSAM4W modem, the Main Antenna and the Ethernet Cable must
be properly connected.
The antennas are positioned on the Main & DIV Antenna Connector on the Right Side Panel. The Ethernet cable and
power supply cable is plugged in the appropriate port on the Left Side Panel.
9
Ver1.3
