Ultra SAM4W User Guide V1.3
TEMPLATE:
1.
Access UltraSAM4W Main Page, Enter APN/PIN and achieved Public IP condition.
2.
Internet Setting -> VPN -> Ipsec
3.
Click Add button to create a new profile
4.
Fill in parameter
Remote Ipsec Gateway
Remote Address/Net to Join
Remote Address/Net Mask
Local Address/Net to Join
Local Address/Net Mask
Encap Protocol
IKE Mode
Pfs
IKE Encryption
Ipsec Hash
DH Group
DPD Action
DPD Keep Alive Time
DPD Timeout
IKE Rekey Time
SA Life Time
Key Mode
Pre Shared Key
Remote ID
Local ID
5.
After parameters entry, click Save to store & activate the Ipsec feature
6.
If using another UltraSAM4W for another side, all parameters should be similar except the Addressing
35
Remote Gateway Public IP Address
Remote Gateway Local IP Address
th
(the 4
group set to be "0" represent 1~255, 192.168.1.0 represent
192.168.1.1 ~ 192.168.1.255)
Remote Gateway Local IP Address Net Mask
Local Address IP Address
th
(the 4
group set to be "0" represent 1~255, 192.168.2.0 represent
192.168.2.1 ~ 192.168.2.255)
Local Address Net Mask
ESP
Main
On
AES
MD5
Group2 (1024)
None
10
60
3600
28800
Pre Shared Key
customer defined (example: 123456)
customer defined
customer defined
Ver1.3
