TABLE 15-2: PIC16F87XA INSTRUCTION SET
Mnemonic,
Operands
ADDWF f, d Add W and f
ANDWF f, d AND W with f
CLRF f Clear f
CLRW - Clear W
COMF f, d Complement f
DECF f, d Decrement f
DECFSZ f, d Decrement f, Skip if 0
INCF
f, d Increment f
INCFSZ f, d Increment f, Skip if 0
IORWF f, d
Inclusive OR W with f
MOVF f, d Move f
MOVWF f Move W to f
NOP - No Operation
RLF f, d Rotate Left f through Carry
RRF f, d Rotate Right f through Carry
SUBWF f, d Subtract W from f
SWAPF f, d
Swap nibbles in f
XORWF f, d Exclusive OR W with f
BCF f, b Bit Clear f
BSF f, b Bit Set f
BTFSC f, b Bit Test f, Skip if Clear
BTFSS f, b Bit Test f, Skip if Set
ADDLW k Add Literal and W
ANDLW k AND Literal with W
CALL k Call Subroutine
CLRWDT - Clear Watchdog Timer
GOTO k Go to Address
IORLW k Inclusive OR Literal with W
MOVLW k Move Literal to W
RETFIE - Return from Interrupt
RETLW k Return with Literal in W
RETURN - Return from Subroutine
SLEEP - Go into Standby mode
SUBLW k Subtract W from Literal
XORLW
k Exclusive OR Literal with W
Note 1: When an I/O register is modified as a function of itself ( e.g., MOVF PORTB, 1), the value used will be that value present
on the pins themselves. For example, if the data latch is '1' for a pin configured as input and is driven low by an external
device, the data will be written back with a '0'.
2: If this instruction is executed on the TMR0 register (and where applicable, d = 1), the prescaler will be cleared if
assigned to the Timer0 module.
3: If Program Counter (PC) is modified, or a conditional test is true, the instruction requires two cycles. The second cycle is
executed as a NOP.
Note: Additional information on the mid-range instruction set is available in the PICmicro
Family Reference Manual (DS33023).
