Pro-Form VIBE 980 ZL User Manual page 7

2. Attach the Lower Upright (B) to the Base (A)
with four M8 x 48mm Screws (E) and four M8
Split Washers (F).
3. Orient the Wheel Assembly (D) as shown.
Attach the Wheel Assembly (D) to the Base (A)
with three M5 x 14mm Screws (G).
4. While a second person holds the Upper Upright
(C) near the Lower Upright (B), connect the
upper wires to the lower wires.
Next, attach the Upper Upright (C) to the Lower
Upright (B) with an M6 x 16mm Screw (H).
2
A
F
E
F
E
3
A
D
G
4
C
Upper
Wire
Lower
Wire
7
B
H
B
