R&S SMF100A
[:SOURce<hw>]:PULM:TRAin:DEXChange:AFILe:SEParator:DECimal <Decimal>
Select the decimal separator used in the ASCII data between '.' (decimal point) and ','
(comma) with floating-point numerals.
Parameters:
<Decimal>
Example:
Options:
Manual operation:
[:SOURce<hw>]:PULM:TRAin:DEXChange:EXECute
Starts the export or import of the selected file. When import is selected, the ASCII file is
imported as pulse train list. When export is selected, the pulse train list is exported into
the selected ASCII file.
Example:
Usage:
Options:
Operating Manual 1167.2319.02 ─ 12
DOT | COMMa
*RST: DOT
PULM:TRA:DEXC:MODE EXP
selects that the pulse train list is exported into an ASCII file.
MMEM:CDIR '/var/user/Lists/import'
selects the directory for the ASCII files with on-time/off-time/
repetition values.
PULM:TRA:DEXC:AFIL:SEL 'train.csv'
selects ASCII file train.csv as destination for the pulse train list
data.
PULM:TRA:DEXC:AFIL:SEP:COL TAB
the ontime/offtime/repetition values are separated by a tabulator.
PULM:TRA:DEXC:AFIL:SEP:DEC DOT
selects the decimal separator dot.
PULM:TRA:DEXC:SEL 'train_imp'
selects that the pulse train list train_imp is imported into
ASCII file train.csv.
R&S SMF-K27 (Pulse Train)
See " Decimal Point - ASCII File Settings "
PULM:TRA:DEXC:MODE IMP
selects that ASCII files with ontime/offtime/repetition values are
imported and transferred into pulse train lists.
MMEM:CDIR '/var/user/Lists/import'
selects the directory for the ASCII files with on-time/off-time/
repetition values.
PULM:TRA:DEXC:AFIL:SEL 'train.csv'
selects that ASCII file train.csv is imported.
PULM:TRA:DEXC:SEL 'train_imp'
selects that the ASCII file train.csv is imported into pulse
train list train_imp.
PULM:TRA:DEXC:EXEC
starts the import of the ASCII file data into the pulse train file.
Event
R&S SMF-K27 (Pulse Train)
Remote Control Commands
SOURce Subsystem
on page 303
