Chapter 8: PID Loop Operation

Process Control Definitions

1
Manufacturing Process – the set of actions that adds value to raw materials. The process can
involve physical changes and/or chemical changes to the material. The changes render the
2
material more useful for a particular purpose, ultimately used in a final product.
Process Variable – The controlled variable part of the process that you wish to control. It may
3
be temperature, pressure, level, flow, composition, density, the ratio of two streams, etc. Also
known as the actual value.
4
Setpoint – This is the target for the process variable. When all conditions of the process are
correct, the process variable will equal the setpoint.
5
Control Output – The result of the loop calculation, which becomes a command for the
process (such as the heater level in an oven). This is sometimes referred to as control variable.
Error Term – The algebraic difference between the process variable and the setpoint. This is
6
the control loop error, and is equal to zero when the process variable is equal to the setpoint
(desired) value. A well-behaved control loop is able to maintain a small error term magnitude.
7
Manipulated Variable – This is what is used to effect the controlled variable. For example, the
fuel used in a furnace might be manipulated in order to control the temperature.
8
Disturbance – Something in the system that changes such that corrective action is required.
For instance, when controlling a flow and the upstream pressure drops, the control valve must
9
open wider in order to keep flow constant. The drop in upstream pressure is the disturbance.
Final Control Element – This is the physical device used to control the manipulated variable.
10
Valves are probably the most widely used final control element.
Lag Time – The time it takes for the process to respond to a change in manipulated variable.
11 This is also known as the capacitance of the system. When you're in the shower and you turn
up the hot water a little, the time it takes before the water gets hot is the lag time.
Dead Time – The time it takes for a change in the process to be recognized. Composition
12
analyzers and quality control are usually sources of significant dead time.
Loop Configuring – Operator-initiated selections which set up and optimize the performance
13
of a control loop. The loop calculation function uses the configuration parameters in real time
to adjust gains, offsets, etc.
14
Loop Monitoring – The function which allows an operator to observe the status and
performance of a control loop. This is used in conjunction with the loop configuring to
A
optimize the performance of a loop (minimize the error term).
B
C
D
