Port 2 Setup for RLL Using K-Sequence, DirectNET or Modbus RTU

V7655 (Word 1)
0yyy 0ttt mmmm mxx
V7656 (Word 2)
K-Sequence, Direct NET
& Modbus RTU
pps0 ebbb xaaa aaaa
V7656 (Word 2) cont'd
K-Sequence, Direct NET
Appendix K: Introduction to Serial Communications
Timeout
RTS On-delay
(% of timeout)
yyy
000 = 0ms 000 = 100%
001 = 2ms 001 = 120%
010 = 5ms 010 = 150%
011 = 10ms 011 = 200%
100 = 20ms 100 = 500%
101 = 50ms 101 = 1000%
110 = 100ms 110 = 2000%
111 = 500ms 111 = 5000%
Parity Stop Bits
pp
00 = None 0 = 1 bit
10 = Odd 1 = 2 bits
11 = Even
( Direct NET)
& Modbus RTU
pps0 ebbb xaaa aaaa
DL05 Micro PLC User Manual, 6th Edition, Rev. A
Protocol
ttt mmmmm
10000 = K-Sequence
01000 = Direct NET
00100 = Modbus RTU
Echo Suppression
s e
0 = 232 or 422
1 = 485, 2 wire
Protocol Secondary Address
xaaaaaaa ( Direct NET)
_aaaaaaa (K-Seq. &
x
Modbus RTU)
0 = Hex K-Sequence: 1-90
1 = ASCII Direct NET: 1-90
Modbus:
RTS Off-delay
xxx
000 = 0ms
001 = 2ms
010 = 5ms
011 = 10ms
100 = 20ms
101 = 50ms
110 = 100ms
111 = 500ms
Baud Rate
bbb
000 = 300
001 = 600
010 = 1200
011 = 2400
100 = 4800
101 = 9600
110 = 19200
111 = 38400
1-247
