Profile Parameter Table

V7630 is a pointer location which points to the
beginning of the Profile Parameter Table. The
default starting location for the profile parameter
table is V2320. However, you may change this by
programming a different value in V7630.
Remember to use the LDA (load address)
instruction, converting octal into hex.
The HSIO uses the next V-memory register past
the bottom of the profile parameter table to
indicate profile errors. See the error table at the
end of this section for error code definitions.

Trapezoidal Profile

V-Memory
V2320, bits 12 – 15
V2320,
V2321/ 2322
V2323
V2324
V2325
V2326
*
To set a negative number, put 8 in the most significant digit. For example: 8388608 is 88388608 in V2321 and
V2322.

Registration Profile

V-Memory
V2320, bits 12 – 15
V2320, bits 0 – 11
V2321/ 2322
V2323
V2324
V2325
V2326
*
To set a negative number, put 8 in the most significant digit. For example: 8388608 is 88388608 in V2321 and
V2322.

Velocity Profile

V-Memory
V2320
V2321/ 2322
V2323
V2326
Appendix E: High-speed Input and Pulse Output Features
Function
Trapezoidal Profile
Target Velocity Value
Target Position Value *
Starting Velocity
Acceleration Time
Deceleration Time
Error Code
Function
Registration Profile
Target Velocity Value
Target Position Value* –8388608 to 8388607
Starting Velocity
Acceleration Time
Deceleration Time
Error Code
Function
Velocity Profile
Direction Select 80000000=CCW, 0=CW
Velocity
Error Code
