Appendix A: Auxiliary Functions

Introduction

A

Purpose of Auxiliary Functions

Many CPU setup tasks involve the use of Auxiliary (AUX) Functions. The AUX Functions
2
perform many different operations, including clearing ladder memory, displaying the scan
time, and copying programs to EEPROM in the handheld programmer. They are divided
3
into categories that affect different system resources. You can access the AUX Functions from
DirectSOFT 5 or from the D2–HPP Handheld Programmer. The manuals for those products
provide step-by-step procedures for accessing the AUX Functions. Some of these AUX
4
Functions are designed specifically for the Handheld Programmer setup, so they will not be
needed (or available) with the DirectSOFT 5 package. Even though this Appendix provides
5
many examples of how the AUX functions operate, you should supplement this information
with the documentation for your choice of programming device.
6
NOTE: The Handheld Programmer may have additional AUX functions that are not supported with the
DL05 PLCs.
7
8
AUX 2* — RLL Operations
21
22
9
23
24
10
AUX 3* — V-Memory Operations
31
11
AUX 4* — I/O Configuration
41
AUX 5* — CPU Configuration
12
51
53
13
54
55
56
14
57
58
A
59
5B
5D
B
C
D
A–2
DL05 Micro PLC User Manual, 6th Edition, Rev. A
AUX Function and Description
Check Program
Change Reference
Clear Ladder Range
Clear All Ladders
Clear V Memory
Show I/O Configuration
Modify Program Name
Display Scan Time
Initialize Scratchpad
Set Watchdog Timer
Set Communication Port 2
Set Retentive Ranges
Test Operations
Override Setup
HSIO Interface Configuration
Scan Control Setup
*
NOTE: - Supported HP - Handheld Programmer function
DL05 AUX Function and Description
AUX 6* — Handheld Programmer Configuration
*
61 Show Revision Numbers
*
62 Beeper On / Off
*
65 Run Self Diagnostics
*
AUX 7* — EEPROM Operations
71 Copy CPU memory to HPP EEPROM
*
72 Write HPP EEPROM to CPU
73 Compare CPU to HPP EEPROM
74 Blank Check (HPP EEPROM)
*
75 Erase HPP EEPROM
76 Show EEPROM Type (CPU and HPP)
*
AUX 8* — Password Operations
*
81 Modify Password
*
82 Unlock CPU
*
83 Lock CPU
*
*
*
*
*
*
DL05
*
HP
HP
HP
HP
HP
HP
HP
HP
*
*
*
