Appendix E: High-speed Input and Pulse Output Features

Pulse Output Error Codes

1
The Profile Parameter Table starting at V2320 (default location) defines the profile. Certain
numbers will result in a error when the HSIO attempts to use the parameters to execute a
2
move profile. When an error occurs, the HSIO writes an error code in V2326.
Most errors can be corrected by rechecking the Profile Parameter Table values. The error is
3
automatically cleared at powerup and at Program-to-Run Mode transitions.
D
E
6
7
8
9
10

Troubleshooting Guide for HSIO Mode 30

11
If you're having trouble with Mode 30 operation, please study the following symptoms and
possible causes. The most common problems are listed below:
1

Symptom: The stepper motor does not rotate.

Possible causes:
1
1. Configuration – Verify that the HSIO actually generates pulses on outputs Y0 and Y1. Watch the
status LEDs for Y0 and Y1 when you start a motion profile. If the LEDs flicker on and off or are
steadily on, the configuration is probably correct.
14
2. Programming error – If there are no pulses on Y0 or Y1 you may have a programming error.
Check the contents of V2326 for an error code that may be generated when the PLC attempts to
A
do the move profile. Error code descriptions are given above.
3. Check target value – The profile will not pulse if the count value is equal to the target value
B (ex. count = 0, target= 0)
C
D
E–42
DL05 Micro PLC User Manual, 6th Edition, Rev. A
Error Code
0000
0010
0020
0021
0022
0030
0040
0041
0042
0050
0051
0052
0060
0061
0062
Error Description
No error
Requested profile type code is invalid (must use 0, 1, 2, 8, or 9)
Target Velocity is not in BCD
Target Velocity is specified to be less than 40 pps
Target Velocity is specified to be greater than 7,000 pps
Target Position value is not in BCD
Starting Velocity is not in BCD
Starting Velocity is specified to be less than 40 pps
Starting Velocity is specified to be greater than 1,000 pps
Acceleration Time is not in BCD
Acceleration Time is zero
Acceleration Time is greater than 10 seconds
Deceleration Time is not in BCD
Deceleration Time is zero
Deceleration Time is greater than 10 seconds
