Section 7
iVIZION Entire Unit Parts List
Ref No.
EDP No.
1
148069
148070
2
230495
210454
149468
3
219100
214104
4
214105
5
206387
6
226099
7
226100
Refer to "iVIZION Optional Components - Bezel/Harness Parts List" on page 7-47 for optional
OP
Bezels.
P/N 960-100929R_Rev. 7 {EDP #148849}
iVIZION® Series Next-Generation Banknote Acceptor Unit
Table 7-1 iVIZION Entire Unit Parts List
Description
iVIZION Validation Unit
iVIZION Transport Unit (SS)
iVIZION Transport Unit (SH)
iVIZION Transport Unit (LD)
iVIZION Frame Unit
iVIZION Frame Unit without Nut
iVIZION Cash Box (S)
iVIZION Cash Box (L)
iVIZION LD Frame Unit
iVIZION HC Frame Unit
iVIZION HC Cash Box
© 2017, JAPAN CASH MACHINE CO., LTD.
7 - 2
Exploded Views & Parts Lists
Qty
Remark
1
1
1
1
1
1
1
500 notes
1
900 notes
1
1
1
3000 notes
