JCM Products Quick Reference Guide 200 Units Note: Some of the information in this guide may change over time, depending on the soft- ware and possible modifications with advance- ments in technology. For further detailed information pertaining to procedures and troubleshooting methods, please contact our Technical Support Division of Cus- tomer Service.
Page 2
200 Units Quick Reference Troubleshooting Guide Description Probable Cause Possible Solutions Dip switches not set Set Dip switches Bill properly Rejection Roller and/or belts are Clean head and rollers excessively dirty with mild soap and water solution Credit limit not set Set credit limit for properly on game proper acceptance...
Page 3
200 Units Abnormal Initialization Codes # of Description Possible Cause Blinks • Cashbox may be FULL Cashbox Full • Motor not functioning • Sensor not working • Encoder gear cracked or split • Pusher mechanism may be Jam in Cashbox jammed •...
Page 4
200 Units Bill Return Codes Use with Stand-Alone Test w/Rejections, or Host Simulator # of Description Possible Cause Blinks Crooked insertion • Bill was inserted crooked • Entrance sensor malfunction Magnetic pattern error • Error detecting magnetic pattern on a bill/note Acceptor detected a •...
Page 5
Important Note: After wiping, inspect the lenses to ensure that none of the lenses have been moved out of position, or are not flush with the bill path. Note: JCM does not recommend cleaning cards, cleaning pads, or cleaning solutions of any kind CASHBOX PREVENTIVE MAINTENANCE (P/M) Do periodic PM on the cashboxes to ensure proper operation.
200: DIP Switch Settings Basic Operations U.S. “$” Dollar Denomination/Interface use Diagnostic Use $1 $5 $10 $20 $50 $100 * * I/F * Not Applicable NOTE: When Dip switches are in the “ON” position, it disables the acceptance of that bill denomination. DBV-200 ID-004/Bar (I/F) “On”: Accept Coupons &...
Page 7
200: Auto-Calibration 1. Power Off 2. Set DIP Switch DS2: 4,5, and 6 “On.” Denomination/Interface use Diagnostic Use 3. Power-on Unit (plug in the 6-pin connector) 4. Head motor will cycle and stop - Ready to Calibrate 5. Insert the DBV-200 calibration paper, black side first (Part No. 057619).
Page 8
200: In-Field Stand-Alone Test Mode Set the Dip switches then apply power to the unit to accomplish this function Note: Perform this test outside the game using the game power (6- pin) connector, or power supply hook-up • Before applying power, turn Dip switch “6” to “On”. •...
Page 9
DS2 - All to the “On” position. DT-004 - All to the “Off” position. 4. Harnessing • For standard DBV-200 SS/SH/SU units, use the following JCM parts: • PS15-007 Power Supply, Part No. 550-100040, with adaptive harness Part No. 400-100067.
Page 10
200: DT-004 Downloading (Cont’d.) 8. While downloading, the download status LEDs on the DT-004 will illuminate, indicating status of the download. 9. When the downloading is complete, the “OK” LED will light and a buzzer will sound for about a second. 10.Press the “RESET”...
Page 11
200: DT-004 Examples of ID Interface Usage This is an example of the various usages for JCM interfaces DBV - I/F ID Interface OEM (Gaming Manufacturer) ID-004/Bar JCM Standard: CDS and VLC ID-011/015 Sigma and Videotronic ID-022/023 IGT: S-Slots, P.E., P.E. Plus...
Page 12
3 Canale Drive, Ste. #4 Egg Harbor, NJ 08234 Office (609) 677-8909 Fax (609) 677-8820 Southern Region 4063 Ginger Dr., Ste. B Biloxi, MS 39532 Office (228) 354-8600 Fax (228) 354-8608 DBV-200 Quick Reference Manual 2001, JCM American Corp. Part No. 960-000028...
