Note: Some of the information in this guide may change
over time, depending on the software and possible modifica-
tions with advancements in technology.
For further detailed information pertaining to procedures and
troubleshooting methods, please contact our Technical
Support Division of Customer Service.
(702) 651-3444
Parts Sales
(702) 651-3445
E-Mail: techsupport@jcm-american.com
JCM Products
Quick Reference Guide
"WBA
Technical Support
www.jcm-american.com
Units"
TM
(800) 683-7248
Service Department
(702) 651-3446
Advertisement
Related Manuals for JCM WBA
Summary of Contents for JCM WBA
- Page 1 JCM Products Quick Reference Guide “WBA Units” Note: Some of the information in this guide may change over time, depending on the software and possible modifica- tions with advancements in technology. For further detailed information pertaining to procedures and troubleshooting methods, please contact our Technical Support Division of Customer Service.
- Page 2 “WBA Units” Quick Reference Troubleshooting Guide Description Probable Cause Possible Solutions Dip switches not set Set Dip switches Bill properly Rejection Roller and/or belts are Clean head & rollers excessively dirty with mild soap and water solution Denomination disabled Check game options on game.
- Page 3 Diagnostic Tests Test Test When to Use Function Name Spins the motor in a When conducting Transfer forward direction tests #8 and #9 and Motor Test motor is not heard (Forward) Spins the motor in a Same as above Transfer reverse direction Motor Test (Reverse)
- Page 4 “WBA Units” How to Initiate the Standard Tests 1. Set Dip switch #8 to the “ON” position, all others to the “OFF” position. This puts the unit in Test Mode. 2. Apply power connector. 3. Select a Test Mode from the list below, and set the Dip switches accordingly.
- Page 5 “WBA Units” Dip Switch Settings for Head Sensor Sub-Test Magnetic Non-magnetic 1 WBA-1x WBA 2x PLEV FLEV Reserved PT-1/PT-3 PT-1 PT-2/PT-4 PT-2 PT-1/3 PT-2/4 UHPL/DHPL UHPR/DHPR Reserved UHPC/DHPC (“X” in a Column = Switch ON) During these tests, Dip switch No. 6 becomes the enable/disable switch.
- Page 6 “WBA Units” Unit Error Codes: Bill Receiving Test # of Blinks Description Possible Cause Cashbox full • Cashbox may be full • Stack motor not spinning • Sensor not working • Stacker encoder gear blade split Stacker jam • Stacker may be...
- Page 7 Bill Return Codes with and without cashbox # of Blinks Description Possible Cause Crooked insertion • WBA-10, 11, 12, 13 Sensor PT1 or PT2 not working • WBA-20, 21, 22, 23 Sensor PT3 or PT4 not working • Bill inserted crooked Magnetic pattern error •...
-
Page 8: Preventive Maintenance
Do Not use alcohol for cleaning Note: JCM does not recommend - cleaning cards, cleaning pads, or cleaning solutions of any kind. Important Note: After wiping, inspect lenses to ensure that none have been moved out of position, or are not flush with the path. - Page 9 $50 $100 Off (Dir) “On” :2-way acceptance {if within firmware} “Off” :4-way acceptance {if within firmware} WBA-10/11/12/13 ID-022/023 (IGT) Sw-1 Sw-2 Sw-3 Sw-4 Sw-5 Sw-6 Sw-7 Sw-8 (Dir) “On” :2-way acceptance {if within firmware} “Off” :4-way acceptance {if within firmware} (I/F) “On”...
-
Page 10: When To Calibrate
Auto-Calibration - Sensors Description Calibration sets a starting reference point for all optical sensors within the unit. This can be done at the host unit or at the work bench with just a power source. When to Calibrate • After the Acceptor’s components have been disassembled for repair. - Page 11 Auto-Calibration Error Conditions Chart Look at the indicator LED connected to the test harness, or the bezel light. If the LED blinks from 1 to 11 times at 1/2 second intervals, an error exists. Count the number of blinks and match with the list below.
- Page 12 - In Field Stand-Alone Test Mode Accomplish this function by applying power to the unit’s Transport and Head only. Note: Perform this test outside the game using an extension harness, or power supply hook-up. • Remove power. • Prior to starting, set the Dip switches. Place Dip switches 1,2,3 &...
- Page 13 5. Turn the power switch on the DT-004 to the “ON” position. The Power LED should light. 6. Verify the LEDs on the WBA CPU board are illuminated, and are blinking back and forth. This indicates download mode. (Continued )
- Page 14 - DT-004 Downloading (con’t) 7. To begin the download process, press the “START” button. The “RDY” LED will begin to blink. 8. While downloading, the download status LEDs on the DT-004 will illuminate, indicating status of the download. 9. When the downloading is complete, the “OK” LED will light and a buzzer will sound for about a second.
- Page 15 Examples of ID Interface Usage This is an example of the various usages for JCM interfaces WBA - I/F ID Interface OEM (Gaming Manufacturer) ID-003 JCM Standard: Aristocrat, Atronics, Bally, CDS, Sigma, VLC, and WMS ID-022/023 IGT: S-Slots, P.E., P.E. Plus...
- Page 16 3 Canale Drive, Ste. #4 Egg Harbor, NJ 08234 Office (609) 677-8909 Fax (609) 677-8820 Southern Region 4063 Ginger Dr., Ste. B Biloxi, MS 39532 Office (228) 354-8600 Fax (228) 354-8608 WBA Quick Reference Manual 2001 JCM American, Corp. Part No. 960-000027...
