b. If using a non-PoE switch:

i. Use a standard RJ-45 cable to connect the camera to a PoE Injector.

ii. Use a standard RJ-45 cable to connect the PoE Injector to the non-PoE switch.

iii. Use a standard power cable to connect the PoE Injector to a power outlet.

If using the DC12V for the power Supply. The RJ45 cable will be data transmission.

Step 4. Install the EasyConfig Software

Insert the CD into the CD-ROM, and follow the instructions of the InstallShield Wizard to finish

installation.
