Page 1: User Manual
WOP-12ac User manual, Version 1.8 (09.2016) Wireless access point IP-адрес: http://192.168.1.10 User Name: admin Password: password... - Page 2 Version 1.2 16.04.2015 Synchronization with firmware version 1.5.0 Added section: - 2.5 The device structural diagram - 2.8 Order specification Version 1.1 10.02.2015 Added: Technical parameters of antennas Version 1.0 26.09.2014 First issue Firmware version 1.8.0 _____________________________________________________________________________ User manual, WOP-12ac...
-
Page 3: Table Of Contents
3.5.1 Procedure of attaching brackets to the device ................ 15 3.5.2 Order of the device mounting to a pole/pillar ................. 15 3.5.3 Order for wall-mounting brackets ................... 18 3.5.4 Grounding scheme of the device ..................... 19 APPENDIX А. POWER CONNECTOR PINOUT ....................20 _____________________________________________________________________________ User manual, WOP-12ac... -
Page 4: Introduction
WOP-12ac device is a Wi-Fi access point of Enterprise class. Construction of the device has hermetic enclosure that allows you to use the device as an outdoor access point in different climate... -
Page 5: Device Description
____________________________________________________________________________ 2 DEVICE DESCRIPTION 2.1 Propose WOP-12ac wireless access point (hereinafter the device) is designed for provision of users’ access to high-speed, safe network. The device provides high-speed and safe wireless network combining a lot of opportunities and services that are necessary for comfortable users’ access to operator services. - Page 6 Opportunity to set priority on the base of IP, Ethertype, TCP/UDP port and etc. Safety – E-mail informing about system events; – Centralized authorization via RADIUS server (WPA Enterprise); – WPA/WPA2 data encryption; – Support Captive Portal. _____________________________________________________________________________ User manual, WOP-12ac...
-
Page 7: The Device Technical Parameters
- AC 220 В (optionally) Power adapter has a protection function against power line surges by using smoothing filter IP protection class IP-57 Electromagnetic compatibility Power consumption Up to 14 W range of operation temperatures From -40 to +60°С _____________________________________________________________________________ User manual, WOP-12ac... - Page 8 Polarization dual H&V Radiating angle (horizontal polarization) 90°(-3 dB), 120°(-6 dB) Radiating angle (vertical polarization) 6° <1,8 Impedance 50 Ohm Front-to-back ratio > 35 dB Standard IIEEE 802.11a/n/ac WLAN Systems Size 580x125x50 mm Weight 1.5 kg _____________________________________________________________________________ User manual, WOP-12ac...
-
Page 9: Design
____________________________________________________________________________ 2.4 Design WOP-12ac has an industrial design and metal case. Figure 1 shows the device side panel layout. Figure 1 – WOP-12ac side panel layout Connectors and controls located on the device panels are listed in Table Table 2.4. -
Page 10: Reset To The Default Settings
Power supply unit Port 0 (PoE) Port 1 Console Power connector Figure 2 – WOP-12ac schematic diagram – A1-A6 – connector for antenna connection; – Radio 1, Radio 2 – radio interfaces that performs reception and transmission of data in wireless network;... -
Page 11: Delivery Package
Connector for ground; – Mounting kit; – Documentation. 2.8 Order specification – WOP-12ac DC; – Injector, 802.3at (PoE+), Ethernet 10/100/1000 Base-T; – Pin antenna with circular pattern (Omni); – Sectoral antenna (Sector 120 ) (antenna-feeder device in set). _____________________________________________________________________________ User manual, WOP-12ac... -
Page 12: Installation Order
8. You should satisfy established standards and requirements for working at height during the device installation on the high-rise constructions. 9. The device exploitation should be performed by engineering and technical personnel with special training. 10. Connect only to operational service equipment. _____________________________________________________________________________ User manual, WOP-12ac... -
Page 13: Installation Recommendations
-1,8 Plaster with wirecloth -14,8 -13,2 Breezeblock Metal lattice (mesh 13*6 mm, metal 2mm) 3.4 Channel selection for neighboring access points It is recommended to set nonoverlapping channels to avoid interchannel interference between neighboring access points. _____________________________________________________________________________ User manual, WOP-12ac... -
Page 14: The Device Installation
Figure 6 – Channels used in range of 5GHz when channel width is 20, 40 or 80 MHz 3.5 The device installation The device is attached to pole/pillar or wall in accordance with the safety instruction and recommendations listed above. _____________________________________________________________________________ User manual, WOP-12ac... -
Page 15: Procedure Of Attaching Brackets To The Device
Align four boltholes on brackets with the same boltholes on the device. Attach brackets with screws to the device by using screw-driver. 3.5.2 Order of the device mounting to a pole/pillar 1. Mount the bracket for attaching to a pole: _____________________________________________________________________________ User manual, WOP-12ac... - Page 16 Fix bracket on pole by using clamps, see Figure 9. b. Install DIN7985 M6 screws in the top holes. Do not screw them fully. Leave 3 mm gap as minimum, see Figure 9. 3. Attach the device to a pole: _____________________________________________________________________________ User manual, WOP-12ac...
- Page 17 Install the device on the top untwisted screws of a bracket attached to a pole, see Figure Figure 10. b. Install screws in the bottom bolthole, see Figure Figure 10. c. Tight up the top and bottom screws by using screwdrive. _____________________________________________________________________________ User manual, WOP-12ac...
-
Page 18: Order For Wall-Mounting Brackets
Align together four boltholes on bracket and boltholes on the device surface. Screw the brackets to the device surface by using screwdrive. c. Install DIN7985 M6 screws in the top holes. Do not screw them fully. Leave 3 mm gap as minimum, see Figure 11. _____________________________________________________________________________ User manual, WOP-12ac... -
Page 19: Grounding Scheme Of The Device
Tight up the top and bottom screws by using screwdrive. 3.5.4 Grounding scheme of the device After device installation, you must ground it by using 2.5 mm vinyl-insulated wire. Figure 14 shows grounding scheme of the device Figure 14 – The device grounding scheme _____________________________________________________________________________ User manual, WOP-12ac... -
Page 20: Appendix А. Power Connector Pinout
Table - RJ45-DB9 connector pinout Serial Port (RJ-45 Connector) Pin Adapter (DB-9) Pin 3 (TXD) 2 (RXD) 4 (Signaling Ground) 5 (Signaling Ground) 5 (Signaling Ground) 5 (Signaling Ground) 6 (RXD) 3 (TXD) Figure below shows embodiment: _____________________________________________________________________________ User manual, WOP-12ac... - Page 21 +7(383) 272-83-31, E-mail: techsupp@eltex.nsk.ru Visit Eltex official website to get the relevant technical documentation and software, benefit from our knowledge base, send us online request or consult a Service Centre Specialist in our technical forum: Eltex official website: http://eltex.nsk.ru Технический форум: http://eltex.nsk.ru/forum Knowledge base: http://eltex.nsk.ru/support/knowledge...
